Matrix Comsec

ANANT PMS USER10

Rs. 1,074.15

~~Rs. 1,181.57~~ Rs. 1,074.15

Sale Sold out

ANANT PMS USER10

License to enable Property Management System (PMS) Interface for ANANT UCS.

For ANANT UCS
Number of Users: 10
Integrates with Third-Party Property Management Systems (PMS)
Hospitality functions and features used in Hotels and Motels

Note: ANANT PMS USER10 requires ANANT HOSPITALITY USER10 to be pre-activated.

OPEN SERVER BASED PBX

ANANT Unified Communication Software (ANANT UCS) is an enterprise-grade, hardware-independent Unified Communication solution designed to replace traditional hardware-based PBXs. It provides flexibility, scalability, mobility, and seamless communication across multiple locations.

Employees can connect from anywhere using Matrix VARTA on laptops, tablets, PCs, and smartphones. ANANT UCS offers enterprise-grade calling features, built-in redundancy, and integration with VoIP gateways and IP phones.

Product Highlights

Feature	Capacity
IP Users	5000
Concurrent Calls	1024
Three-Party Conferences	512
Simultaneous Call Recordings	64

Key Features

Hardware Independence
Active-Standby Redundancy
RAID1 and RAID5 Support
Mobility
Auto Sign-in for Softphone
LDAP Client Support
Built-in Auto-Attendant and Voicemail
Auto Sync Configuration
Scheduled Backup
Integration with VoIP Gateways
Unified Messaging
Room Monitor
Least Cost Routing
Hotline

Technical Specifications

Parameter	Details
SIP Extensions	5000
SIP Trunks	99
Maximum Transcoding Audio Calls (G.711 a-Law/u-Law)	Based on Resources (Max. 1024)
Maximum Transcoding Audio Calls (G.729)	Based on Resources (Max. 1024)
Maximum DRTP/RTP Relay Audio Calls	1024
Maximum DRTP/RTP Relay Video Calls	102
Maximum Voicemail Channels	64
Maximum Conference Participants (System Wide)	1536
Maximum 3-Party Conferences	512
Maximum Participants in Single Multi-Party / Dial-In Conference	64
Maximum Call Tapping / Recordings	64
Audio Codecs	G.729, G.711 (A-law, μ-law), G.722, iLBC (30 ms, 20 ms)
Supported IETF RFCs	3261, 3262, 3389, 3550, 3551, 3311, 3265, 4733, 2915, 2916, 2327, 2833, 2806, 768, 793, 1034
Network Protocols	IPv6, IPv4, TCP, UDP, SNTP, ARP, ICMP, PPP, DNS, SMTP, STUN
VoIP Quality of Service	Layer 2/3 CoS/QoS for SIP and Layer 3 QoS for RTP
Security	SRTP/TLS over SIP, MD5 Authentication for SIP, AES128 Password Encryption
Configuration	Web-Based Intuitive GUI, Jeeves

Server Specifications

Parameter	Details
Server Model	Any
Processor Model	Intel Xeon E-2134 or Above
CPU Speed	3.5 GHz or Above
CPU Core / Thread	4 / 8
Max Turbo Frequency	4.5 GHz or Above
Cache	8 MB Smart Cache
RAM	8 GB DDR4 ECC
Hard Disk	1 TB (1 No.) – Without RAID Support 1 TB (2 Nos.) – With RAID1 Support 1 TB (3 Nos.) – With RAID5 Support
Form Factor	1U (Rack)
RAID Controller (Optional)	H330 RAID Controller
