Matrix Comsec

ANANT REDUNDANCY USER10

Rs. 2,166.15

~~Rs. 2,382.77~~ Rs. 2,166.15

Sale Sold out

Features of ANANT REDUNDANCY USER10

License to enable redundancy functionality for ANANT UCS.

Platform	ANANT UCS
Number of Users	10
License Activation	Activated on Primary Server Hardware
Feature Behavior	All feature licenses are duplicated on secondary hardware when primary fails

Note: Additional redundant server hardware is required. No license activation is required on the secondary (redundant) server for redundancy functionality.

Download PDF

OPEN SERVER BASED PBX

ANANT Unified Communication Software (ANANT UCS) is an enterprise-grade, scalable, and hardware-independent communication platform designed to replace traditional PBXs with flexible server-based architecture.

It reduces hardware dependency, simplifies upgrades, and supports modern IP-based unified communication across organizations.

Users can connect using laptops, tablets, PCs, and smartphones via Matrix VARTA, enabling mobility and centralized communication with high availability.

PRODUCT HIGHLIGHTS

Feature	Capacity
IP Users	5000
Concurrent Calls	1024
Three-Party Conferences	512
Simultaneous Call Recording	64

KEY FEATURES

Hardware Independence
Active-Standby Redundancy
RAID1 and RAID5 Support
Mobility Support
Auto Sign-in for Softphone
LDAP Client Integration
Built-in Auto-Attendant and Voicemail
Auto Sync Configuration
Scheduled Backup
Integration with VoIP Gateways
Unified Messaging
Room Monitoring
Least Cost Routing
Hotline Feature

TECHNICAL SPECIFICATIONS

Parameter	Details
SIP Extensions	5000
SIP Trunks	99
Maximum Transcoding Audio Calls	Up to 1024 (resource-based)
Maximum DRTP/RTP Relay Audio Calls	1024
Maximum DRTP/RTP Relay Video Calls	102
Maximum Voicemail Channels	64
Maximum Conference Participants	1536
Maximum 3-Party Conference	512
Maximum Single Conference Participants	64
Maximum Call Recording	64
Audio Codecs	G.729, G.711, G.722, iLBC
Network Protocols	IPv6, IPv4, TCP, UDP, DNS, SMTP, STUN
Security	SRTP/TLS, MD5 Authentication, AES128 Encryption
Configuration	Web-Based GUI (Jeeves)

SERVER SPECIFICATIONS

Parameter	Details
Processor	Intel Xeon E-2134 or above
CPU	4 Core / 8 Thread, 3.5 GHz+
RAM	8 GB DDR4 ECC
Storage	1 TB (Single / RAID1 / RAID5 options)
Form Factor	1U Rack
RAID Controller	H330 (Optional)
