ANANT REDUNDANCY USER50

Rs. 10,897.95

~~Rs. 11,987.75~~ Rs. 10,897.95

Sale Sold out

Product Details

Features of ANANT REDUNDANCY USER50

License to enable redundancy functionality for ANANT UCS.

Platform	ANANT UCS
Number of Users	50
License Activation	Activated on Primary Server Hardware
Redundancy Behavior	All feature licenses are duplicated on secondary hardware when primary fails

Note: Additional redundant server hardware is required. No license activation is required on the secondary server for redundancy functionality.

Download PDF

OPEN SERVER BASED PBX

ANANT Unified Communication Software (ANANT UCS) is a scalable, enterprise-grade communication platform designed to replace traditional hardware-based PBXs with flexible server-based architecture.

It reduces hardware dependency, lowers maintenance effort, and enables unified IP-based communication across organizations.

Users can connect using laptops, tablets, PCs, and smartphones via Matrix VARTA, enabling seamless mobility and communication.

PRODUCT HIGHLIGHTS

Feature	Capacity
IP Users	5000
Concurrent Calls	1024
Three-Party Conferences	512
Simultaneous Call Recording	64

KEY FEATURES

Hardware Independence
Active-Standby Redundancy
RAID1 and RAID5 Support
Mobility Support
Auto Sign-in for Softphone
LDAP Client Integration
Built-in Auto-Attendant and Voicemail
Auto Sync Configuration
Scheduled Backup
Integration with VoIP Gateways
Unified Messaging
Room Monitoring
Least Cost Routing
Hotline Feature

TECHNICAL SPECIFICATIONS

Parameter	Details
SIP Extensions	5000
SIP Trunks	99
Maximum Transcoding Audio Calls (a-Law/u-Law)	Based on Resources (Max. 1024)
Maximum Transcoding Audio Calls (G.729)	Based on Resources (Max. 1024)
Maximum DRTP/RTP Relay Audio Calls	1024
Maximum DRTP/RTP Relay Video Calls	102
Maximum Voicemail Channels	64
Maximum Conference Participants (System Wide)	1536
Maximum 3-Party Conference	512
Maximum Participants (Single Conference)	64
Maximum Call Recording	64
Audio Codecs	G.729, G.711, G.722, iLBC
Network Protocols	IPv6, IPv4, TCP, UDP, DNS, SMTP, STUN
Security	SRTP/TLS, MD5, AES128
Configuration	Web-Based GUI (Jeeves)

SERVER SPECIFICATIONS

Parameter	Details
Processor	Intel Xeon E-2134 or above
CPU	3.5 GHz, 4 Core / 8 Thread
RAM	8 GB DDR4 ECC
Storage	1 TB (Single / RAID1 / RAID5 options)
Form Factor	1U Rack
RAID Controller	H330 (Optional)
