COSEC ARGO FACEE

[caption id="attachment_26720" align="aligncenter" width="716"] COSEC ARGO FACEE[/caption]

CREDENTIAL SUPPORT
Human Face	Yes
PIN	Yes
Card	EM Prox
BLE - Mobile	Yes
CAPACITY
User Profiles	50,000
Face Templates	200,000
Max. Templates Per User	30
Event Logs	500,000
Face Recognition
Algorithm	Deep Learning-based Face Recognition
Fake Face Detection	Yes
Face Identification	1:200,000 in < 1 sec 1:1 in < 0.5 sec
Face Enrolment	Enrolment Station Upload Images
GENERAL SPECIFICATIONS
Dimensions (HxWxD)	186mm x 74 mm x 50mm (7.3” x 3” x 2 “)
Weight	650gms (1.433 lbs)
Display Display Resolution Gorilla Glass	3.5" IPS LCD (Touch Screen) 480 x 320 Pixel Yes (Gorilla Glass 3)
CPU GPU RAM	Quad Core ARM Cortex-A7 @ 1.5 GHz Built-in 2 TOPS Neural Network Computing Performance 2 GB DDR4
Flash Memory SD Card Tamper Detection	16 GB eMMC No (Built-in 16GB eMMC provided) Yes



Buzzer IR LEDs Ingress Protection	Yes Yes IP65
Ingress Protection Certificate Operating Temperature	IK06 CE, FCC, BIS, UL, RoHS 0°C to 50°C
Storage Temperature Humidity	-20°C to 60°C 5% to 95 % RH Non-Condensing
CAMERA
RGB Camera	2MP Surveillance Grade, IR Blocked
Infrared Camera	2MP Surveillance Grade, IR Band Pass
Camera Sensors	SONY IMX 307, EXMOR Technology, STARVIS Series
COMMUNICATION
Ethernet	Yes (10/100 Mbps - 1 port)
PoE	Yes (IEEE 802.3 af)
WiFi	Yes (802.11 b/g/n)
3G/4G/LTE	Yes (Additional USB Modem)
BLE	Yes (8m Range)
USB	Yes (USB 2.0) Micro USB-Type B
INTERFACE
Exit Switch Interface	Yes
External Reader Support	Yes (MATRIX and 3rd Party)
External Reader	Interface ·  RS232 ·  Wiegand Power ·  12VDC @ 0.5A LED and Buzzer Control ·  Allowed - GREEN LED
Wiegand	Yes (Selectable IN/OUT) IN: 26 Bit format OUT: Configurable
Door Lock Relay	Yes (30VDC @ 2A, Dry Contacts NO/NC/COM)
Door Lock Power	Internal PoE Power: 12VDC @ 0.250 A Internal Adapter Power 12VDC @ 0.5 A External Power 12VDC @ 2A
INSTALLATION
Wall Mount	Yes - Plastic Back Cover with Screws
Flush Mount	Yes - Metal Bracket with Screws
ACCESSORIES
Power Adapter	12VDC @ 2A (CE, FCC, UL, BIS)
