DS-2CD3743G1-IZS

Camera

• Image Sensor - 1/3" Progressive Scan CMOS
• Min. Illumination - Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR
• Shutter Speed - 1/3 s to 1/100,000 s
• Slow Shutter - Yes
• Wide Dynamic Range - 120dB
• Day & Night - IR Cut Filter
• Angle Adjustment - Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°

Lens

• Focus - Auto
• Lens Type - 2.7 to 13.5 mm
• FOV - Horizontal FOV: 106° to 27°, vertical FOV: 56° to 16°, diagonal FOV: 128° to 31°
• Aperture - F1.6
• Lens Mount - Φ14
• Auto-Iris - DC drive

Illuminator

• IR Range - Up to 40 m
• Wavelength - 850nm

Video

• Max. Resolution - 2688 × 1520
• Main Stream - 50Hz: 25fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720)
• Sub-Stream - 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
• Third Stream - 50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240)
• Video Compression - Main stream: H.265/H.264 Sub-stream/third stream: H.265/H.264/MJPEG
• Video Bit Rate - 256 Kbps to 16 Mbps
• H.264 Type - Main Profile/High Profile
• H.265 Type - Main Profile
• H.264+ - Main stream supports
• H.265+ - Main stream supports
• Region Of Interest (ROI) - 5 fixed region for main stream and sub-stream

Audio

• Environment Noise Filtering - Yes
• Audio Sampling Rate - 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
• Audio Compression - G722.1/G.711/G726/MP2L2/PCM/MP3
• Audio Bit Rate - 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8Kbps-320Kbps(MP3)

Network

• Simultaneous Live View - Up to 6 channels
• API - ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome
• Protocols - TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
• User/Host - Up to 32 users,3 levels: Administrator, Operator and User
• Network Storage - MicroSD/SDHC/SDXC card (128 GB), local storage and NAS (NFS,SMB/CIFS), ANR Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
• Clienti - VMS-4200, Hik-Connect, Hik-Central
• Web Browser - Plug-in required live view: IE8+ Plug-in free live view: Chr2ome 57.0+, Firefox 52.0+, Safari 11+ Local Service: Chrome 41.0+, Firefox 30.0+
• Alarm Trigger - Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)


• Day/Night Switch - Day/Night/Auto/Schedule/Triggered by alarm in(-S)
• Target Cropping - Yes
• DNR3D DNR
• Image Enhancement - BLC/3D DNR/HLC
• Image Settings - Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser

Interface

• Audio - 1 input (line in/mic.in, 3.5 mm), 1 output (line out, 3.5 mm), mono sound
• Alarm - 1 input, 1 output (max. 12 VDC, 30 mA), terminal block
• Video Output - 1Vp-p Composite Output(75Ω/BNC) (For adjustment only)
• On-Board Storage - Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
• Hardware Reset - Yes
• Communication Interface1 RJ45 10M/100M self-adaptive Ethernet port

Event

• Basic Event - Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
• Smart Event - Line crossing detection, 1 line configurable Intrusion detection, up to 1 region configurable Unattended baggage detection, 1 region configurable Object removal detection, 1 region configurable Face detection: detects faces Scene change detection
• Face Detection - Yes
• Exception Detection - Scene change detection

General

• Linkage Method - Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output , Email
• Firmware Version - V5.6.0
• General Function - Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
• Startup And Operating Conditions -  -30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
• Power Supply - 12 VDC ± 25%, terminal block PoE (802.3af, class 3)
• Power Consumption And Current - 12 VDC, 0.8A, max. 10W PoE (802.3af, 37V to 57V), 0.35A to 0.2A, max. 12W
• Camera Dimension - Camera: Φ 153.3 × 111.6mm (Φ 6" × 4.4")
• Camera Weight - Camera: Approx. 835g (1.8 lb.) With Package: Approx. 1305g (2.9 lb.)

Approval

• Protection - IK10，IP67
