EC-20M-EC-20K

The eSSL EC-20M and EC-20K are elevator access control solutions designed for secure and efficient floor management in multi-storey buildings. The EC-20M functions as the main elevator controller, while the EC-20K operates as an extension board to increase floor output capacity. Together, they deliver reliable and scalable elevator access control for commercial and residential applications.

Key Highlights

• 20 Floor Control: Supports elevator access management for up to 20 floors.
• Large User Capacity: Stores access permissions for up to 20,000 card users.
• High Transaction Storage: Maintains up to 100,000 access records.
• TCP/IP Communication: Enables real-time data transmission and centralized integration.
• Reader Compatibility: Supports Wiegand 26/34 card and biometric readers.

Features

• Primary Controller: EC-20M acts as the main elevator access control unit.
• Expandable Design: EC-20K extension boards increase system output capacity.
• Power Failure Protection: Access data is retained during power interruptions.
• Emergency Support: Supports fire alarm signal input for emergency operation.
• Centralized Management: Integrates with access control management systems.

Elevator Controller - EC-20M

• Controller Function: Manages elevator access permissions and floor control.
• Floor Capacity: Supports access control for up to 20 floors.
• User Capacity: Stores up to 20,000 card users.
• Transaction Storage: Records up to 100,000 access transactions.
• Communication: Uses TCP/IP for system connectivity.
• Reader Interface: Supports Wiegand 26/34 card and biometric readers.
• Fire Alarm Input: Includes emergency fire signal input.

Extension Board - EC-20K

• Expansion Function: Adds additional elevator floor control outputs.
• Output Lines: Provides 20 independent output lines per board.
• Maximum Expansion: Supports connection of up to two EC-20K boards.
• Integration: Designed to work seamlessly with EC-20M controller.

Technical Specifications
