eSSL BL-5-7 Electric Bolt lock (5 Wires)

eSSL BL-5-7 Electric Bolt Lock (5 Wires)

The eSSL BL-5-7 is a fail-safe electric bolt lock designed for access control applications requiring high security and reliable door locking. The lock is installed on the door frame, while the pin casing is installed on the door. When powered with 12V DC, the bolt remains on standby until the magnetic sensor detects proper alignment and automatically secures the door.

Key Features

• Fail-safe operation (Power-off to unlock)
• 12V DC operating voltage
• Built-in magnetic sensor for automatic locking
• Adjustable time delay setting: 0 / 3 / 6 seconds
• Door status signal output (NC / COM)
• Anti-tamper protection
• Automatic relocking within 5 seconds if the door is not opened
• Suitable for access control and security systems

Technical Specifications

Safety Features

• Fail-safe design for emergency exit requirements
• Automatic locking after door alignment detection
• Door automatically relocks within 5 seconds if not opened
• Built-in anti-tamper protection
• Door status monitoring output for system integration

Applications

• Access control systems
• Office entrances
• Glass doors
• Wooden and metal doors
• Commercial buildings
• Secure restricted areas

Why Choose eSSL BL-5-7?

• Reliable fail-safe electric bolt mechanism
• Integrated magnetic sensor for automatic locking
• Adjustable locking delay settings
• Supports door status monitoring
• Ideal for professional access control installations

Package Includes

• 1 × BL-5-7 Electric Bolt Lock
• 1 × Strike Plate
• Installation Accessories
• User Manual
