eSSL

eSSL EML600-7-ZL

Rs. 0.00

Sale Sold out

eSSL EML600-7-ZL Electromagnetic Lock

The eSSL EML600-7-ZL is a high-performance electromagnetic lock designed for access control applications. With a holding force of 600 lbs, stainless steel bolt construction, and built-in LED magnetic bond sensor, it provides reliable and secure door locking for commercial and residential installations.

Key Features

600 lbs holding force for enhanced security
12V DC operating voltage
LED magnetic bond sensor for lock status indication
16 mm stainless steel bolt
Low standby power consumption
Compact and durable construction
Suitable for access control and security systems

Technical Specifications

Specification	Details
Model	EML600-7-ZL
Product Type	Electromagnetic Lock
Face Plate Dimensions	205 × 35 × 40 mm (L × W × H)
Strike Plate Dimensions	90 × 25 × 2 mm (L × W × H)
Cover Plate Dimensions	215 × 40 × 0.7 mm (L × W × H)
Operating Voltage	DC 12V
Current Draw (Start)	950 mA
Current Draw (Standby)	120 mA
Bolt	16 mm Diameter, 16 mm Stainless Steel
Holding Capacity	600 lbs
Operating Temperature	10°C to 55°C
LED Indicator	Magnetic Bond Sensor
Net Weight	0.64 kg
Gross Weight	0.80 kg
