Product Details
InBio-460 Pro Plus – 4-Door Biometric Access Controller
The InBio-460 Pro Plus is a powerful Linux-based biometric door controller designed for centralized access control across multiple doors. Supporting up to four doors, the controller provides flexible connectivity for fingerprint, card, QR code, and other compatible readers through RS-485 and Wiegand interfaces.
With a default capacity of 30,000 cards, expandable up to 100,000 cards with a license, 20,000 fingerprints, and 500,000 transactions, the InBio-460 Pro Plus is suitable for offices, commercial buildings, factories, institutions, and other applications requiring reliable multi-door access management.
Key Features
Controls up to four doors from a single centralized controller, simplifying access management for multi-door installations.
Supports 30,000 cards as standard and can be expanded up to 100,000 cards with an appropriate license, along with 20,000 fingerprint templates.
Stores up to 500,000 access transactions, making it suitable for high-traffic environments and long-term event management.
Supports up to 8 RS-485 readers or 4 26-bit Wiegand readers, providing flexible reader deployment across the four controlled doors.
Supports access levels, time zones, holidays, anti-passback, interlock, multi-card opening, remote door control, and multiple verification methods.
Provides real-time access monitoring through a web browser, allowing administrators to monitor and manage connected doors from a centralized platform.
Provides dedicated connections for door status sensors, exit devices, auxiliary inputs, locks, alarms, and auxiliary relay outputs.
Network connectivity through TCP/IP enables centralized communication between the controller and access control management software.
Reader Support
- 26-bit Wiegand Card Readers
- RS-485 Card Readers
- Up to 8 RS-485 Readers
- Up to 4 Wiegand Readers
- QR Code Reader through compatible Wiegand interface
Access Control Functions
- 256 Time Zones
- 256 Access Levels
- Holiday Management
- Anti-Passback
- Global Anti-Passback
- Interlock Function
- Global Interlock
- Linkage Function
- Multi-Card Opening
- Multiple Verification Methods
- Remote Door Opening and Closing
- Advanced Access Control Options
- Real-Time Monitoring
Input & Output Interfaces
- 4 Exit Device Inputs
- 4 Door Status Inputs
- 4 Auxiliary Inputs
- 4 Form-C Lock Relays
- 4 Form-C Auxiliary Relays
- 4 Door Sensors
- 4 Exit Buttons
- 4 Alarm Outputs
Specifications
| Parameter | Specification |
|---|---|
| Model | InBio-460 Pro Plus |
| Category | Door Controller |
| Operating System | Linux OS |
| Number of Doors | 4 Doors |
| Card Capacity | 30,000 Standard / Up to 100,000 with License |
| Fingerprint Capacity | 20,000 |
| Transaction Capacity | 500,000 |
| Communication | TCP/IP |
| RS-485 Readers | Up to 8 |
| Wiegand Readers | Up to 4 × 26-bit Wiegand Readers |
| Supported Reader Types | 26-bit Wiegand and RS-485 Readers |
| Inputs | 12 Total: 4 Exit Device, 4 Door Status, 4 AUX Inputs |
| Outputs | 8 Total: 4 Form-C Lock Relays + 4 Form-C Auxiliary Relays |
| Access Control Interface | Wiegand, RS-485, Lock, Door Sensor, Exit Button, Alarm |
| Mounting | Wall Mount |
| Power Supply | 9.6V – 14.4V DC |
| Operating Temperature | 0°C to 45°C |
| Operating Humidity | 20% to 80% RH, Non-condensing |
| Dimensions | 226 × 106 × 36.07 mm |
| TCP/IP | 1 Port |
| RS-485 | 8 Ports |
| Wiegand | 4 Ports |
| Auxiliary Inputs | 4 |
| Auxiliary Outputs | 4 |
| Locks | 4 |
| Door Sensors | 4 |
| Exit Buttons | 4 |
| Alarm | 4 |
Supported Software & Database
The controller is supported with eSSL BioCVSecurity 6.4.1 Web Version for centralized access control management and real-time monitoring.
The default database is PostgreSQL (PGSQL), with Microsoft SQL Server (MSSQL) and Oracle available as alternate database options.
PC Requirements
- Operating System: Windows 10 or above
- RAM: 16 GB recommended
- Antivirus / Firewall: Should be disabled during software installation; it can be configured after installation
Applications
- Corporate Offices
- Commercial Buildings
- Factories and Industrial Facilities
- Educational Institutions
- Warehouses
- Government Buildings
- Multi-Door Access Control Systems
- Enterprise Security Systems
Frequently Asked Questions
The InBio-460 Pro Plus is designed to control up to four doors from a single controller.
The controller supports up to eight RS-485 readers or four 26-bit Wiegand readers, depending on the selected installation architecture.
The standard card capacity is 30,000 and can be expanded up to 100,000 with a license. The controller supports up to 20,000 fingerprints and 500,000 transactions.
Yes. Compatible QR code readers can be connected through the supported Wiegand access control interface.
Yes. The system supports anti-passback as well as global anti-passback functionality for enhanced access control.
Yes. The system supports remote door opening and closing through the access control management software.
Yes. Real-time monitoring is available through a web browser using the supported access control software.
The default database is PostgreSQL, while MSSQL and Oracle can be used as alternate database platforms.
