eSSL ET-2000 Full Height Turnstile – Stainless Steel Pedestrian Gate

Rs. 71,718.00

~~Rs. 93,233.00~~ Rs. 71,718.00

Sale Sold out

eSSL ET-2000 One-Way Bridge Tripod Turnstile

The eSSL ET-2000 is a heavy-duty bridge-type tripod turnstile designed to provide secure and efficient pedestrian access control for offices, factories, educational institutions, transportation hubs, stadiums, and commercial facilities. Featuring a robust SUS304 stainless steel housing, semi-automatic operation, and support for biometric and RFID integration, the ET-2000 ensures smooth, controlled entry with a reliable "one person, one passage" mechanism.

Heavy-Duty Construction

Manufactured with premium SUS304 stainless steel for superior durability, corrosion resistance, and long operational life.

High Throughput Performance

Supports up to 35 persons per minute, making it ideal for medium and high-traffic access points.

Advanced Access Control Integration

Compatible with RFID readers, fingerprint devices, and access control systems for secure pedestrian management.

Emergency Safety Features

Supports emergency switch input and drop-arm functionality for safe evacuation during emergencies.

Key Features

Bridge-Type Heavy Duty Tripod Turnstile.
One-Way and Bi-Directional Operation.
Semi-Automatic Controller.
Automatic Reset of Barrier Arms.
Adjustable Timeout Delay.
Single Passage and Free Passage Modes.
Emergency Drop Arm Function.
Dry Contact Input Control Signal.
Compatible with RFID and Fingerprint Readers.
Low Maintenance and Long Service Life.
Suitable for Indoor and Semi-Outdoor Installations.

Technical Specifications

Specification	Details
Model	ET-2000
Category	Bridge Type Bidirectional Tripod Turnstile
Passage Width	550 mm
Throughput Rate	35 Persons/Minute
Power Supply	100V – 240V AC
Operational Voltage	24V DC
Maximum Power Consumption	30W
Frequency	50 – 60Hz
Maximum Arm Tolerance	80 Kg
Angle Per Rotation	120°
Input Control Signal	Dry Contact
Protection Rating	IP44
Working Temperature	-25°C to +70°C
Electro-Magnetic Drive	DC
Dimensions (L × W × H)	1200 × 280 × 980 mm (Excluding Bar)
Net Weight	52 Kg (Including Bar)
Opening Duration	5 – 60 Seconds (Adjustable)
MCBF	5 Million Cycles
CPU	32-bit Microprocessor
Housing Material	SUS304 Stainless Steel
Barrier Arms	Stainless Steel
Integrated Controller	InBio-260
User Capacity	30,000 RFID Users
Fingerprint Capacity	3,000 Fingerprints
Transaction Capacity	100,000 Records
Fire Alarm Support	Yes
Reader Compatibility	RFID / Fingerprint Readers
Communication Protocol	RS485 / Mifare / Proximity (Optional)
