BioMax FLB-162 Flap Barrier Gate
The BioMax FLB-162 is a premium flap barrier gate engineered for secure, intelligent, and high-speed pedestrian access control. Designed with a robust AISI304/AISI316 stainless steel housing and durable acrylic or polycarbonate barrier flaps, it offers smooth and reliable operation for offices, corporate buildings, airports, metro stations, educational institutions, and other high-security environments.
Supporting IC cards, ID cards, barcode, and magnetic card authentication, the FLB-162 integrates seamlessly with access control, attendance, and ticketing systems. Equipped with infrared safety sensors, anti-clipping protection, voice alerts, and automatic reset functionality, it delivers enhanced security while ensuring a comfortable user experience.
Key Features
Multiple Credential Support
Compatible with IC cards, ID cards, barcode cards, and magnetic cards for access control, attendance, and ticketing applications.
Advanced Infrared Safety Protection
Multiple infrared sensors detect unauthorized entry, prevent tailgating, and ensure safe pedestrian passage.
Double Anti-Clipping System
Combines photocell and mechanical anti-clipping technology to protect users during barrier operation.
Voice & LED Status Alerts
Integrated voice prompts, strobe light alerts, and direction indicators provide clear operational guidance and security notifications.
Automatic Reset & Adjustable Closing Delay
Automatically resets if no passage occurs after authorization and supports adjustable barrier closing delay from 1 to 60 seconds.
Heavy-Duty Stainless Steel Construction
Manufactured with corrosion-resistant AISI304 stainless steel with optional AISI316 housing and durable acrylic or polycarbonate barrier wings.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | BioMax |
| Model | FLB-162 |
| Product Type | Flap Barrier Gate |
| Passage Width | ≥ 550 mm |
| Throughput Rate | 35 Persons/Minute |
| Power Supply | 100–240V AC, 50/60 Hz |
| Operating Voltage | 24V DC |
| Maximum Power Consumption | 35 W |
| Frequency | 50–60 Hz |
| Protection Rating | IP44 |
| Operating Temperature | -25°C to 70°C |
| Housing Material | AISI304 Stainless Steel (Optional AISI316) |
| Barrier Material | Acrylic / Polycarbonate (PC) / Stainless Steel Frame |
| Dimensions (L × W × H) | 1410 × 340 × 1005 mm |
| Net Weight | 75 kg |
| Supported Credentials | IC Card, ID Card, Barcode Card, Magnetic Card |
| Operating Modes | Single Direction, Bi-Directional, Free Passage, Always Locked / Always Free |
Applications
- Corporate Offices
- Commercial Complexes
- Airports
- Metro & Railway Stations
- Educational Institutions
- Government Buildings
- Banks & Financial Institutions
- Data Centers & High-Security Facilities
Why Choose BioMax FLB-162?
The BioMax FLB-162 combines elegant design, intelligent access control, and advanced safety technology in a high-performance flap barrier system. With infrared anti-tailgating detection, double anti-clipping protection, automatic reset, voice alerts, and durable stainless steel construction, it provides a secure, efficient, and professional solution for modern pedestrian access management.
