eSSL GO-O-29 Overhead Swing Gate Motor – Up to 300kg Gate Automation
eSSL GO-O-29 Overhead Swing Gate Motor – Up to 300kg Gate Automation
📞 Call 9315441078 for Best Price
Couldn't load pickup availability
eSSL GO-O-29 Swing Gate Opener
The eSSL GO-O-29 is a high-performance automatic swing gate opener designed for residential, commercial, and industrial gate automation applications. Powered by a reliable 24V DC brushless motor, the GO-O-29 delivers smooth, quiet, and efficient gate operation with intelligent safety functions, soft start and stop technology, and support for various access control systems.
24V DC Brushless Motor
High-efficiency brushless motor provides stable operation, low noise, and a service life of up to 2 million cycles.
Advanced Safety Protection
Automatically reverses during closing and stops during opening when an obstacle is detected.
Soft Start & Soft Stop
Ensures smooth operation, reduces mechanical wear, and extends the lifespan of the gate automation system.
Access Control Integration
Supports connection with photocells, radar sensors, face recognition systems, card readers, fingerprint devices, and fire alarm systems.
Key Features
- 24V DC Voltage Drive for Safe Operation.
- DC Brushless Motor with Accurate Limit Control.
- Long Service Life up to 2 Million Cycles.
- Self-Designed Gearbox with Low Running Noise.
- Soft Start and Soft Stop Function.
- Auto-Close Function Available.
- Obstacle Detection and Reverse Protection.
- LED Status Indication.
- IP54 Weather Protection for Outdoor Installation.
- Supports Single and Double Gate Installation.
- Compatible with External Access Control Devices.
- Fire Alarm Linkage Interface.
Technical Specifications
| Specification | Details |
|---|---|
| Model | GO-O-29 |
| Product Type | Automatic Swing Gate Opener |
| Motor Power | 24VDC / 90W |
| Motor Type | DC Brushless Motor |
| Motor Rotational Speed | 1500 RPM ±10% |
| Open / Close Time | 5 – 15 Seconds (Adjustable) |
| Maximum Opening Angle | 120° |
| Maximum Gate Width | 1800 mm |
| Maximum Gate Weight | 180 kg |
| Working Temperature | -20°C to +55°C |
| Protection Class | IP54 |
| Operating Life | Up to 2 Million Cycles |
| Installation Type | Single or Double Swing Gate |
Safety Features
- Automatic reverse when obstacle is detected during closing.
- Stops immediately when obstacle is detected during opening.
- Motor self-lock functionality.
- Photocell safety support.
- Over-current and over-time protection.
- Error diagnosis and fault indication.
- Manual release operation during power failure.
Supported Integrations
- Face Recognition Devices
- Fingerprint Readers
- RFID Card Readers
- Microwave Radar Sensors
- Infrared Sensors
- Electromagnetic Locks
- Electric Bolt Locks
- Fire Alarm Systems
- RS485 Communication Devices
Applications
- Residential Villas
- Apartment Complexes
- Corporate Offices
- Educational Institutions
- Hospitals
- Factories & Warehouses
- Commercial Buildings
- Hotels & Resorts
- Government Facilities
- Industrial Premises
Why Choose eSSL GO-O-29?
- Powerful 24VDC/90W brushless motor.
- Suitable for gates up to 180 kg and 1.8 m width.
- Long service life of up to 2 million cycles.
- Smooth and quiet operation.
- Advanced obstacle protection technology.
- IP54 weatherproof design for outdoor use.
- Easy integration with access control systems.
- Supports both single and double gate applications.
Package Includes
- 1 × GO-O-29 Swing Gate Opener
- Motor Assembly
- Arm Set
- Mounting Plate
- Control Unit
- Remote Transmitter
- Installation Accessories
- User Manual
*Specifications and features are subject to change by the manufacturer without prior notice.
