BioMax KR26M MIFARE RFID Card Reader
The BioMax KR26M is an industrial-grade Wiegand-based MIFARE RFID slave card reader designed for secure access control installations requiring reliable 13.56 MHz smart card authentication. It functions as a slave reader and connects with a centralized access controller or biometric terminal for credential processing.
The KR26M does not store user records, maintain access logs, or control door locks independently. Instead, it captures MIFARE card information at entry or exit points and transfers the card data through the Wiegand interface to a connected master controller, making it ideal for multi-door and enterprise security applications.
Key Features
MIFARE 13.56 MHz Technology
Supports secure MIFARE smart cards operating at 13.56 MHz frequency for reliable contactless identification.
Wiegand 26/34 Communication
Provides standard WG26/WG34 output for seamless integration with access control panels and biometric systems.
IP68 Weatherproof Protection
Fully dust-tight and waterproof design allows reliable operation in outdoor and harsh environmental conditions.
Slave Reader Architecture
Designed as a peripheral reader that transfers card data to a centralized controller without internal storage or relay control.
Long Distance Communication
Supports connection distance up to 100 meters from the host controller for flexible system deployment.
Compact Industrial Design
Slim plastic enclosure allows easy installation on narrow door frames and access points.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | BioMax |
| Model | KR26M |
| Product Type | MIFARE RFID Slave Card Reader |
| Credential Compatibility | MIFARE Smart Cards (13.56 MHz) |
| Output Protocol | Wiegand 26-bit / Wiegand 34-bit |
| Reading Range | 2–5 cm |
| Working Voltage | DC 12V |
| Idle Current | ≤ 30 mA |
| Communication Distance | Up to 100 meters |
| Ingress Protection | IP68 Waterproof & Dustproof |
| Enclosure Material | Heavy-Duty Plastic Case |
| Dimensions | 45 × 110 × 20 mm |
| Certifications | ISO, RoHS, CE, FC |
Hardware Interface
Wiegand Connection Interface
The KR26M uses a weather-sealed rear wiring harness for direct connection with the Wiegand terminal of a master access controller or biometric machine.
Controller Integration
Designed to work with centralized access control systems where card processing and door management are handled by the main controller.
Applications
- Enterprise Access Control Systems
- Outdoor Entry Gates
- Industrial Facilities
- Multi-Door Security Networks
- Corporate Offices
- Warehouses
- Parking Access Systems
- Restricted Access Areas
Why Choose BioMax KR26M?
The BioMax KR26M MIFARE RFID Slave Reader provides secure 13.56 MHz card authentication with industrial durability, IP68 protection, and Wiegand compatibility. Its reliable slave architecture and long-distance communication capability make it an excellent choice for professional access control systems requiring centralized credential management.
