L1 AADHAAR ENABLED BIOMETRIC ATTENDANCE SYSTEM

MBAS20

MANTRA

Applications

Access Control | Time-Attendance | Canteen Management | Banking & Finance

Resource & Manpower Management | School Bus Management & Tracking | Insurance Claim Processing | eKYC

Features

• STQC L1 & FBI PIV Certified Fingerprint Scanner: Ensures precise individual identification.
• 13.56 Mhz Contactless Smart Card Reader: Convenient access control.
• Auto Sleep & Wakeup to Save the Battery Power: Enhances battery life.
• Optimized Thermal Management: Ensures device durability.
• 4000 mAh Battery Backup: Extended usage without interruptions.
• 5MP AF Front Camera with Flash LED: Capture clear images.
• Ethernet / LAN Connectivity: Reliable network connection.
• Android Operating System: Modern and user-friendly interface.
• micro SD Card Slot Supporting up to 32GB Storage: Expandable storage options.
• Barcode Reader with Camera: Enhanced functionality.
• Scratch Free Sensor Surface: Durable and reliable.
• MINEX Compliance Extractor: Compliant with industry standards.
• Auto Finger Detection: Convenient and efficient.

L1 AADHAAR ENABLED BIOMETRIC ATTENDANCE SYSTEM MBAS20 by MANTRA, incorporating relevant keywords: Applications:

• Access Control: The MBAS20 is designed for access control, ensuring only authorized individuals can enter secured areas.
• Time-Attendance: It efficiently records and manages attendance data, making it ideal for workforce management.
• Canteen Management: This system can also be used for canteen access management.
• Banking & Finance: Ensures secure access to financial institutions.
• Resource & Manpower Management: Helps optimize resource allocation and workforce tracking.
• School Bus Management & Tracking: Ensures student safety by monitoring school buses.
• Insurance Claim Processing: Facilitates secure authentication in insurance processes.
• eKYC: Ideal for electronic Know Your Customer (eKYC) processes.

Features:

• STQC L1 & FBI PIV Certified Fingerprint Scanner: The device features certified fingerprint scanning technology for accurate identification.
• 13.56 MHz Contactless Smart Card Reader: Offers contactless card access for enhanced security.
• Auto Sleep & Wakeup: This feature conserves battery power by automatically entering sleep mode when not in use.
• Optimized Thermal Management: Ensures the device operates efficiently even in varying temperatures.
• 4000 mAh Battery Backup: Provides extended usage time without frequent recharging.
• 5MP AF Front Camera with Flash LED: Enhances security with a high-resolution camera for image capture.
• Ethernet / LAN Connectivity: Enables network integration for data management.
• Android Operating System: Employs the Android OS for seamless operation and flexibility.
• micro SD Card Slot: Supports expandable storage for data retention.
• Barcode Reader with Camera: Provides barcode scanning capability for added functionality.
• Scratch-Free Sensor Surface: Ensures durability and longevity of the fingerprint sensor.
• MINEX Compliance Extractor: Complies with MINEX standards for biometric data extraction.
• Auto Finger Detection: Automatically detects and reads fingerprints for user convenience.

Hardware & System Parameters:

• CPU: Employs a powerful ARM Cortex A53 Quad Core Processor for smooth operation.
• Memory: 2GB RAM + 16GB Flash memory for efficient data storage.
• LCD: Features a 7" TFT LCD with high-resolution 1024x600 display.
• Touch: Scratch-resistant multi-point capacitive touch screen with 6H toughened glass.
• Operating System: Runs on Android 10 for enhanced functionality.
• Front Camera: Equipped with a 2MP fixed-focus front camera.
• Back Camera: Features a 5MP auto-focus front camera with Flash LED.
• LED Indicators: Provides power and battery charging status indicators.
• Audio: Includes a high-quality 1W speaker for announcements.
• RTC: Features a real-time clock for accurate timekeeping.
• Object Detection Sensor: Utilizes an IR-based proximity sensor for device auto-sleep and wakeup.
• Control Buttons: Includes power on/off and reset buttons for user control.
• Operating/Storage Temperature: Works efficiently in temperatures ranging from 0°C to 50°C.
• Operating Humidity: Functions in humidity levels from 10% to 90% RH (Non-Condensing).
• Dimensions: Compact dimensions of 221 x 181 x 48 mm for easy installation.
• Weight: Lightweight at approximately 0.8 kg.
• Certifications: Complies with CE, RoHS, BIS, and IP54 standards.

Fingerprint Sensor Parameters:

• Fingerprint Type: Utilizes a scratch-free optical FAP10 L1 sensor for accurate fingerprint scanning.
• Fingerprint Image: Captures fingerprint images at 276 x 336 pixels.
• Image Specs: Images are 500 DPI +/- 2%, with 256 (8-bit gray level) for detailed recognition.
• Certifications: Compliant with CE, FCC Part 15B, RoHS, STQC L1, FBI PIV, EN/IEC 62368-1, IS13252 Part I standards.

Smart Card Reader:

• Compatibility: Supports ISO14443 Type A/B Cards, MIFARE Clasic 1K/2K/4K, MIFARE DESFire Light 1K, MIFARE DESFire EV1/EV2 4K, MIFARE Plus S 2K, NTAG, and Contactless Card (Optional).

Interfaces:

• Connectivity: Supports 2G/3G/4G/GPRS, Wi-Fi, Ethernet, SD Card, Bluetooth, GPS, SIM Socket, DC Jack, Micro USB, RS-485 (Optional), Wiegand (Optional), GPIO (Optional), Relay (Optional), and USB 2.0 (Optional).

Electrical:

• Power Adaptor: Input AC: 90~265V, 50Hz; Output DC: 12V/2.0A.
• Battery Pack: Features a Li-Ion 4000 mAh rechargeable and replaceable battery for extended usage.

The L1 AADHAAR ENABLED BIOMETRIC ATTENDANCE SYSTEM MBAS20 by MANTRA is a versatile and feature-rich solution designed to meet various identification and access control needs. Its advanced technology and robust hardware make it suitable for a wide range of applications, ensuring precise individual identification and enhanced security.
