Matrix SATATYA NVR9608X P2 96 Channel NVR with 4K Support and 8 HDD Slots
Matrix SATATYA NVR9608X P2 96 Channel NVR with 4K Support and 8 HDD Slots
Couldn't load pickup availability
Matrix SATATYA NVR9608X P2 96 Channel NVR with 4K Support and 8 HDD Slots
The Matrix SATATYA NVR9608X P2 is a high-performance 96-channel network video recorder built for demanding surveillance environments. With support for 12MP recording and 4K HDMI output, it delivers crystal-clear video for real-time and playback monitoring. This NVR supports 8 SATA HDDs with up to 18TB per slot, offering massive storage capacity. Advanced features like adaptive recording, mobile alerts, ONVIF compatibility, and NVR cascading make it ideal for centralized, large-scale video management.
Features
96 IP channel inputs with ultra-clear 4K HDMI output
Supports up to 12MP recording resolution for unmatched image clarity
Local decoding of 4x 4K, 10x 3MP, or 16x 1080p for smooth live viewing
8 SATA HDD slots with up to 18TB per slot (HDDs not included)
Adaptive recording and per-camera retention settings to optimize storage
Real-time alerts via SMS, email, video pop-up, and mobile notifications
Mobile monitoring through MATRIX SATATYA SIGHT app
High-speed 512Mbps uplink and downlink for reliable performance
ONVIF support for easy integration with third-party IP cameras
Cascading support to manage multiple NVRs from a central point
Technical Specifications
Video Channels: 96 IP Inputs
Recording Resolutions: 12MP, 8MP, 5MP, 4MP, 3MP, 2MP, 720p, D1, CIF
Decoding Capabilities: 4x 4K, 10x 3MP, 16x 1080p
Video Output: 4K HDMI
Audio I/O: 1 Audio In / 1 Audio Out
Alarm I/O: 2 Alarm In / 1 Alarm Out
Storage: 8 SATA HDD Slots, Max 18TB per slot (HDDs not included)
Throughput: 512Mbps Uplink / 512Mbps Downlink
Mobile Integration: MATRIX SATATYA SIGHT App
Cascading: Centralized control of multiple Matrix NVRs
Compliance: ONVIF Compatible
Why Choose Matrix SATATYA NVR9608X P2?
Designed for large enterprises and critical infrastructure, the Matrix SATATYA NVR9608X P2 offers high channel capacity, ultra HD video, and massive storage. Its smart features and scalability make it the perfect solution for mission-critical surveillance environments.
