Matrix Video Management System Platform with 16 HDD Slots, 64GB RAM, and Cyber Secured VMS

Matrix Video Management System Platform with 16 HDD Slots, 64GB RAM, and Cyber Secured VMS

The Matrix Video Management System Platform is built on enterprise-grade hardware with high-performance specifications for large-scale surveillance. It comes preloaded with Windows 10 IoT Enterprise LTSC 2019 and the SATATYA SAMAS PLT license, offering a secure, reliable, and scalable video monitoring solution. With 16 HDD bays, 64GB RAM, a 16-core Xeon processor, and top-tier GPU and RAID support, this VMS delivers seamless video processing and data protection for mission-critical environments.

Features

3rd Gen 16-core Xeon processor with 64GB RAM for heavy-duty processing
Preloaded with Windows 10 IoT Enterprise LTSC 2019 and SATATYA SAMAS PLT license
16 hot-swap 3.5"/2.5" SATA HDD/SSD bays supporting up to 18TB each (HDD not included)
Dual input hot-swap 875W (1+1) redundant power supply ensures system uptime
2x 10GbE and 2x 1GbE LAN ports with 512Mbps uplink and downlink throughput
Supports Onvif and major brand cameras up to 12MP for flexible integration
Decoding support: 1x 4K, 4x 1080P, 9x 720P, or 16x D1 resolution
Supports H.265, H.264, and MJPEG compression formats for efficient storage
GPU GTX1650 for accelerated performance with hardware RAID controller
Multiple display outputs: HDMI, VGA, DP, and DVI-D
Expandable up to 255 IP camera licenses with advanced security features

Technical Specifications

Processor: 3rd Gen Xeon 16-Core
RAM: 64GB
Storage Bays: 16x 3.5"/2.5" SATA (18TB max each, HDD not included)
OS: Windows 10 IoT Enterprise LTSC 2019
VMS License: SATATYA SAMAS PLT (Expandable)
Network Ports: 2x 10GbE, 2x 1GbE
Video Input: Supports up to 12MP resolution
Decoding: 1 x 4K / 4 x 1080P / 9 x 720P / 16 x D1
Video Compression: H.265, H.264, MJPEG
GPU: GTX1650
RAID: Hardware RAID controller included
Display Outputs: 1x HDMI, 1x VGA, 1x DP, 1x DVI-D
Redundancy: Dual 875W Redundant Power Supply
Throughput: Uplink - 512Mbps / Downlink - 512Mbps
Scalability: Expandable up to 255 IPC
Camera Support: Onvif and major brands

Why Choose Matrix Video Management System Platform?

Designed for enterprise surveillance, this system offers high scalability, secure operations, and smooth video processing. From multi-camera support to high-performance storage and GPU acceleration, it’s built for demanding security environments where uptime, efficiency, and expandability matter most.
