Matrix Comsec

PRASAR REDUNDANCY SME

Rs. 13,427.20

~~Rs. 14,769.92~~ Rs. 13,427.20

Sale Sold out

PRASAR REDUNDANCY SME – Features

License to Enable Redundancy Functionality for PRASAR UCS

Compatibility	For PRASAR UCS SME
Activation	License is activated on Primary SPARK200 hardware
Redundancy Behavior	All feature licenses are duplicated on secondary hardware when primary hardware fails
Hardware Requirement	Additional (redundant) SPARK200 hardware required for redundancy operation
License Requirement	No license activation required on secondary hardware

Anant Server Based UC Platform

⬇ Download Datasheet

OPEN SERVER BASED PBX

ANANT UNIFIED COMMUNICATION SOFTWARE

Traditional hardware-based PBXs are slowly getting replaced by open server-based telephony systems. This is largely because hardware-based PBXs create hardware dependency, require manual up-gradation and incur heavy wiring cost. Matrix has designed an enterprise-grade highly capable, durable, scalable, and efficient Unified Communication Software solution – ANANT UCS.

The hardware-independent platform provides customers with a choice to select a reliable server as per their requirements. With a range of enterprise-grade calling features, it improves employees’ productivity and speeds up the decision-making process.

ANANT UCS connects all the employees on a single platform. The employees can connect from anywhere at any time by installing Matrix VARTA on Laptops /Tablets /PCs /Smartphones devices of their choice.

Our UC Server offers a range of enterprise-grade calling features that improve employees’ productivity and speeds up the decision making process. With an in-call redundant system, ANANT UCS boasts of providing the best customer engagement.

By integrating ANANT with VoIP Gateways and IP Phones, customer requirements with multiple location communication set-up can be met.

PRODUCT HIGHLIGHTS

5000 IP Users
1024 Concurrent Calls
512 Three Party Conference
64 Simultaneous Call Recording

Key Features

Hardware Independence
Active-standby Redundancy
RAID1 and RAID5 Support
Mobility
Auto Sign-in for Softphone
LDAP Client Support
Built-in Auto-attendant and Voicemail
Auto Sync Configuration
Scheduled Back-up
Integration with VoIP Gateways
Unified Messaging
Room Monitor
Least Cost Routing
Hotline

TECHNICAL SPECIFICATIONS

Parameter	Details
SIP Extensions	5000
SIP Trunks	99
Maximum Transcoding Audio Calls (a-Law/u-Law)	Based on Resources (Max. 1024)
Maximum Transcoding Audio Calls (G.729)	Based on Resources (Max. 1024)
Maximum DRTP/RTP Relay Audio Calls	1024
Maximum DRTP/RTP Relay Video Calls	102
Maximum Voicemail Channels	64
Maximum Conference Participants (System Wide)	1536
Maximum 3-Party Conference	512
Maximum Participants in Single Multi-Party/Dial-In Conference	64
Maximum Call Tapping or Recordings	64
Audio Codecs	G.729, G.711 (A-law, μ-law), G.722, iLBC (30 ms, 20 ms)
Supported IETF RFCs	3261, 3262, 3389, 3550, 3551, 3311, 3265, 4733, 2915, 2916, 2327, 2833, 2806, 768, 793, 1034
Network Protocols	IPv6, IPv4, TCP, UDP, SNTP, ARP, ICMP, PPP, DNS, SMTP, STUN
VoIP QoS	Layer 2/3 CoS/QoS for SIP; Layer 3 QoS for RTP
Security	SRTP/TLS over SIP, MD5 Authentication, AES128 Encryption
Configuration	Web-Based Intuitive GUI (Jeeves)

SERVER SPECIFICATIONS

Parameter	Details
Server Model	Any
Processor	Intel Xeon E-2134 or above
CPU Speed	3.5 GHz or above
CPU Core/Thread	4/8
Max Turbo Frequency	4.5 GHz or above
Cache	8 MB Smart Cache
RAM	8 GB DDR4 ECC
Hard Disk	1 TB (1 No.) – Without RAID Support 1 TB (2 Nos.) – RAID1 Support 1 TB (3 Nos.) – RAID5 Support
Form Factor	1U Rack
RAID Controller	H330 (Optional)
