PRASAR VOCODER CHNL4
PRASAR VOCODER CHNL4
Couldn't load pickup availability
Product Details
Features of PRASAR VOCODER CHNL4
License for VOCODER Channels for PRASAR UCS SME and PRASAR UCS ENT
| Supports | 4 Simultaneous Calls with Transcoding |
|---|
⬇ Download Datasheet – PRASAR VOCODER CHNL4
OPEN SERVER BASED PBX
ANANT UNIFIED COMMUNICATION SOFTWARE
Traditional hardware-based PBXs are being replaced by open server-based telephony systems due to hardware dependency, manual upgrade requirements, and high infrastructure cost.
Matrix ANANT UCS is an enterprise-grade unified communication platform designed to be scalable, durable, and hardware-independent, allowing organizations to choose server infrastructure based on their needs.
It connects all employees on a single unified communication platform accessible from laptops, tablets, PCs, and smartphones via Matrix VARTA.
The system improves productivity and decision-making through enterprise-grade voice and collaboration features.
It supports integration with VoIP gateways and IP phones for multi-location communication deployments.
PRODUCT HIGHLIGHTS
- 5000 IP Users
- 1024 Concurrent Calls
- 512 Three Party Conference
- 64 Simultaneous Call Recording
Key Features
- Hardware Independence
- Active-standby Redundancy
- RAID1 and RAID5 Support
- Mobility
- Auto Sign-in for Softphone
- LDAP Client Support
- Built-in Auto-attendant and Voicemail
- Auto Sync Configuration
- Scheduled Back-up
- Integration with VoIP Gateways
- Unified Messaging
- Room Monitor
- Least Cost Routing
- Hotline
TECHNICAL SPECIFICATIONS
| Parameter | Details |
|---|---|
| SIP Extensions | 5000 |
| SIP Trunks | 99 |
| Maximum Transcoding Audio Calls | Based on Resources (Max. 1024) |
| Maximum DRTP/RTP Relay Audio Calls | 1024 |
| Maximum DRTP/RTP Relay Video Calls | 102 |
| Maximum Voicemail Channels | 64 |
| Maximum Conference Participants | 1536 |
| Maximum 3-Party Conference | 512 |
| Maximum Participants in Single Conference | 64 |
| Maximum Call Recording | 64 |
| Audio Codecs | G.729, G.711, G.722, iLBC |
| Network Protocols | IPv6, IPv4, TCP, UDP, DNS, SMTP, STUN |
| Security | SRTP/TLS, MD5 Authentication, AES128 Encryption |
| Configuration | Web-Based GUI (Jeeves) |
SERVER SPECIFICATIONS
| Parameter | Details |
|---|---|
| Server Model | Any |
| Processor | Intel Xeon E-2134 or above |
| CPU Speed | 3.5 GHz or above |
| CPU Core/Thread | 4/8 |
| Max Turbo Frequency | 4.5 GHz or above |
| Cache | 8 MB Smart Cache |
| RAM | 8 GB DDR4 ECC |
| Hard Disk |
1 TB (1 No.) Without RAID 2×1 TB RAID1 Support 3×1 TB RAID5 Support |
| Form Factor | 1U Rack |
| RAID Controller | H330 (Optional) |
