Matrix SATATYA NVR1601X (16 Channel Enterprise 4K Network Video Recorder with 1 HDD Slot)

The Matrix SATATYA NVR1601X is a high-performance 16-channel enterprise Network Video Recorder designed for professional IP surveillance systems. It delivers 4K ultra HD decoding, high throughput performance, and advanced storage optimization for efficient long-term video recording.

Built for small to medium enterprise deployments, this NVR provides centralized monitoring, smart recording management, and seamless integration with ONVIF-compliant IP cameras. It is ideal for organizations requiring reliable, scalable, and high-definition video surveillance.

Key Features

• Supports up to 16 IP camera inputs
• 4K Ultra HD decoding and display support
• Display: HDMI with 1/1 Audio I/O and 2/1 Alarm I/O
• Supports multiple resolutions: 12MP, 8MP, 5MP, 4MP, 3MP, 2MP, 720P, D1 & CIF
• High performance throughput up to 360–512 Mbps (model variant dependent)
• 1 SATA HDD slot (supports up to 10TB, HDD not included)
• ONVIF and major IP camera brand compatibility

Technical Highlights

• IP Channels: 16
• Local Decoding Capability: 5 × 4K / 16 × 3MP / 24 × 1080P / 54 × 720P / 64 × D1
• Video Compression: H.265 / H.264 / MJPEG
• Network Throughput: High bandwidth uplink/downlink support
• Storage Interface: 1 × SATA HDD (up to 10TB)
• Alarm I/O: 2 input / 1 output
• Audio Support: 1/1 Audio I/O

Smart Recording & Storage Features

• Adaptive recording for intelligent storage optimization
• Camera-wise recording retention configuration
• Efficient bandwidth management for long-term recording
• Scheduled, motion-based, and event-based recording modes
• Quick playback and smart search functionality

Remote Monitoring & Alerts

• Mobile app-based live view and playback
• SMS and Email alert notifications
• Video pop-up and alarm-triggered alerts
• Remote configuration and system management
• Centralized monitoring with cascading support

Why Choose Matrix SATATYA NVR1601X?

• Designed for enterprise-grade surveillance systems
• High-speed processing with 4K decoding support
• Reliable 24/7 continuous recording performance
• Scalable architecture for growing security needs
• Supports multiple camera brands via ONVIF protocol
• Optimized storage with adaptive recording technology

Applications

• Corporate offices and IT parks
• Industries and manufacturing plants
• Warehouses and logistics hubs
• Retail chains and shopping complexes
• Educational institutions
• Government and public infrastructure projects

System Benefits

• High-resolution 4K surveillance recording
• Reduced storage consumption through smart compression
• Centralized multi-camera monitoring
• Stable enterprise-grade performance
• Flexible expansion with cascading support

Important Notes

• Hard disk drive is not included with the system
• Storage capacity depends on HDD configuration and usage
• Performance may vary based on camera resolution and bitrate
• Professional installation is recommended for optimal setup

The Matrix SATATYA NVR1601X is a powerful 16-channel enterprise 4K NVR offering high throughput, intelligent recording, and scalable storage management. It is ideal for businesses requiring reliable, high-definition surveillance with centralized control and long-term data retention.
