Matrix Comsec

SETU VFX440

Rs. 16,535.04

~~Rs. 18,188.54~~ Rs. 16,535.04

Sale Sold out

Features of SETU VFX440

VoIP-FXO-FXS Gateway with 4 FXO, 4 VoIP Channels

VoIP Protocol	SIP (9 SIP Accounts)
VoIP Channels	4
FXO Port	4
FXS Ports	0
Ethernet Ports	2
Power Supply (Adaptor Based)	12V DC

Download Datasheet (PDF)

Connect Traditional Telephone Lines to Modern VoIP Networks

The SETU VFX440 is a compact and powerful 4 Port FXO VoIP Gateway designed to connect PSTN telephone lines with SIP-based IP telephony systems. It enables businesses to integrate traditional telecom infrastructure with modern VoIP networks, helping reduce communication costs while extending the life of existing PBX investments.

Designed for growing businesses, branch offices, call centers, and enterprises, the VFX440 offers seamless interoperability with IP-PBX platforms and SIP service providers. With support for multiple SIP accounts, advanced call routing, and enterprise-grade security, it delivers reliable voice communication without disrupting existing business workflows.

Built for Business Communication

Whether you're migrating from legacy telephony, deploying SIP trunking, or connecting multiple office locations, the SETU VFX440 provides a smooth transition between analog and IP environments. The gateway allows organizations to continue using existing PSTN lines while taking advantage of VoIP features, centralized management, and lower operational costs.

Key Highlights

4 FXO ports for PSTN connectivity
Up to 8 VoIP channels
Support for multiple SIP accounts
SIP v2 compliant architecture
Fax over IP (T.38 and Pass-Through)
Advanced echo cancellation for superior voice quality
Secure communication with TLS and SRTP encryption
SNMP monitoring and remote management
Web-based configuration interface
Flexible dialing plans and call routing
Suitable for IP-PBX and SIP trunk deployments
Centralized communication across multiple locations

Applications

SIP Trunk Integration

Connect traditional PSTN lines to SIP-enabled communication systems and reduce calling expenses.

Legacy PBX Modernization

Integrate existing analog PBX systems into modern IP telephony environments without replacing infrastructure.

Multi-Location Businesses

Enable seamless communication between branch offices and headquarters over IP networks.

Contact Centers

Support inbound and outbound calling requirements while maintaining reliable connectivity.

Business Continuity Planning

Ensure uninterrupted communication through intelligent routing and PSTN connectivity options.

Enterprise VoIP Deployments

Provide secure and scalable connectivity between analog telecom networks and SIP platforms.

Technical Specifications

Specification	Details
Product Model	SETU VFX440
Device Type	VoIP-FXO Gateway
FXO Ports	4
FXS Ports	0
VoIP Channels	Up to 8
SIP Accounts	Up to 9
Ethernet Ports	2 × 10/100 Base-T RJ45
VoIP Protocol	SIPv2, SDP, RTP (RFC 2833)
Network Protocols	IPv4, TCP, UDP, PPPoE, DHCP, SNTP, NAT, STUN, HTTP, DynDNS, Port Forwarding, DMZ
Voice Codecs	G.711 A/μ-Law, G.723.1, G.729AB, GSM-FR, iLBC
Echo Cancellation	G.168, Up to 128ms
Fax Support	T.38 Fax Relay & Pass-Through
DTMF Support	RFC 2833, In-band, SIP INFO
Security	SRTP and TLS Encryption
Monitoring	SNMP Support
Auto Provisioning	TR-069
Call Logs	Up to 2,000 Call Records
Management	Web-Based Configuration & Remote Administration
Power Supply	12V DC, 2A Adapter
Typical Power Consumption	5W
Mounting Options	Desktop or Wall Mount
Operating Temperature	0°C to +45°C
Dimensions	15.5 × 22 × 3.5 cm

System Requirements

Component	Requirement
SIP Server	SIP-Compliant IP-PBX or Hosted PBX
VoIP Service	SIP Trunk Provider
PSTN Connectivity	Analog Telephone Lines
Network Infrastructure	Ethernet LAN (10/100 Mbps)
Internet Connection	Broadband or Dedicated IP Connection
Browser Support	Chrome, Edge, Firefox, Safari
IP Configuration	DHCP or Static IP
Power Source	Standard AC Outlet with Included Adapter
Deployment Environment	Indoor Business Installation

Why Businesses Choose SETU VFX440

The SETU VFX440 is ideal for organizations looking to bridge traditional telecom infrastructure with modern VoIP networks without expensive system replacements. Its combination of FXO connectivity, SIP compatibility, enterprise security, and centralized management makes it a practical solution for businesses seeking reliable and cost-effective voice communication.
