Matrix Comsec

SETU VFXTH0016

Rs. 33,090.56

~~Rs. 36,399.62~~ Rs. 33,090.56

Sale Sold out

Features of SETU VFXTH0016

VoIP-FXO-FXS Gateway with 16 FXS, 16 VoIP Channels

VoIP Protocol	SIP (32 SIP Accounts)
VoIP Channels	16
FXO Port	0
FXS Ports	16
Ethernet Ports	1
Power Supply	24V DC (Adaptor Based)

Download PDF

Product Description

SETU VFXTH0016 is a multi-channel VoIP FXS gateway designed to connect traditional analog telephones with modern SIP-based IP networks. It enables seamless integration between 16 analog FXS extensions and VoIP systems, allowing businesses to modernize communication infrastructure while retaining legacy devices.

This gateway is suitable for SMEs, call centers, and multi-branch organizations requiring stable analog-to-IP conversion with centralized VoIP management.

Key Features

16 FXS ports for analog extensions
16 VoIP channels
SIP-based communication support (SIP V2, SDP, RTP)
Supports up to 32 SIP accounts
Seamless analog-to-IP integration
Supports DTMF and pulse dialing
Fax over IP support (T.38 and pass-through)
Carrier-grade voice processing
Web-based configuration and management
Ideal for small to medium enterprise deployments

Technical Specifications

Specification	Details
Product Name	SETU VFXTH0016
Product Type	VoIP FXS Gateway
Brand	Matrix Comsec
VoIP Channels	16
SIP Accounts	Up to 32
FXS Ports	16 Analog Extensions
FXO Ports	0
VoIP Protocols	SIP V2, SDP, RTP (RFC 2833)
Network Interface	1 × 10/100 Base-T Ethernet (RJ45)
Voice Codecs	G.711, G.723.1, G.729AB, iLBC, GSM-FR
Echo Cancellation	G.168 with 128 ms tail length
Fax Support	T.38 and Pass-through
Power Supply	24V DC (External adapter)
Management	Web-based configuration
Function	VoIP ↔ Analog Extension Gateway
