Matrix Comsec

SETU VFXTH0032

Rs. 49,642.24

~~Rs. 54,606.46~~ Rs. 49,642.24

Sale Sold out

Features of SETU VFXTH0032

VoIP–FXO–FXS Gateway with 32 FXS, 32 VoIP Channels

VoIP Protocol	SIP (32 SIP Accounts)
VoIP Channels	32
FXO Ports	0
FXS Ports	32
Ethernet Ports	1
Power Supply	24V DC (Adaptor Based)

Download PDF

Product Description

SETU VFXTH0032 is a high-density VoIP FXS gateway designed to connect analog telephones and legacy communication devices to modern SIP-based IP networks. It enables seamless integration between 32 FXS analog extensions and VoIP systems, making it ideal for enterprises transitioning from traditional PBX infrastructure to IP telephony.

This gateway is widely used in call centers, SMEs, and multi-branch organizations requiring large-scale analog extension connectivity over VoIP networks.

Key Features

32 FXS ports for analog extensions
32 VoIP channels
SIP-based communication support (SIP V2, SDP, RTP)
Seamless analog to IP integration
Supports DTMF and pulse dialing
Carrier-grade voice processing
Web-based configuration and management
High scalability for enterprise deployments
Supports fax and legacy device connectivity

Technical Specifications

Specification	Details
Product Name	SETU VFXTH0032
Product Type	VoIP FXS Gateway
Brand	Matrix Comsec
VoIP Channels	32
SIP Accounts	Up to 32
FXS Ports	32 Analog Extensions
FXO Ports	0
VoIP Protocols	SIP V2, SDP, RTP (RFC 2833)
Network Interface	1 × 10/100 Base-T Ethernet (RJ45)
Dialing Support	DTMF & Pulse Dialing
Echo Cancellation	G.168 (up to 128 ms tail length)
Fax Support	T.38 and Pass-through
Power Supply	24V DC (Adapter Based)
Management	Web-based configuration
Function	VoIP ↔ Analog Extension Gateway
