eSSL UHF1-Tag3 UHF Hard Tag – UHF RFID Credential for Long Range Access

📞 Call 9315441078 for Best Price

UHF1-Tag3 – Ultra High Frequency RFID Tag

The UHF1-Tag3 is a high-performance Ultra High Frequency (UHF) RFID tag designed specifically for long-range vehicle identification and parking management applications. Featuring the reliable G2XM chip, the tag offers excellent metal resistance, high chip sensitivity, and a data retention period of up to 20 years. It is specially designed for installation on vehicle license plates, making it an ideal solution for vehicle access control, parking systems, and electronic toll collection applications.

Key Features

Operates on the global UHF frequency band of 840MHz – 960MHz
Long reading distance up to 10 meters
High-performance G2XM RFID chip
Excellent metal resistance performance
Embedded assembly design for durability
Data retention period up to 20 years
Supports repeated reading and writing operations
Ideal for vehicle and parking management systems
Designed for license plate installation

Product Advantages

Reliable long-range RFID identification
Excellent performance in metal environments
Long service life and high durability
High chip sensitivity for faster reading
Suitable for outdoor applications
Easy installation on vehicle number plates

Technical Specifications

Specification	Details
Model	UHF1-Tag3
Tag Type	Ultra High Frequency RFID Tag
Working Frequency	840MHz – 960MHz
Reading Distance	Up to 10 meters (Depending on reader and environment)
Protocol	ISO/IEC 18000-6C, EPC Global Class 1 Gen 2
Chip	G2XM
Total Memory Capacity	800 Bits
Available Memory Capacity	272 Bits
EPC Memory	96 Bits
UID/TID Memory	64 Bits
User Memory	512 Bits
Access Password	32 Bits
Kill Password	32 Bits
Erase Endurance	10,000 Times
Data Storage	20 Years (Chip Data Retention)
Environmental Compliance	RoHS Certified
Storage Temperature	0°C to 40°C
Storage Humidity	40% – 70% RH
Working Temperature	-30°C to 60°C
Dimensions	249 × 13.8 × 18 mm ±0.5 mm
Installation Method	Fixed on Upper and Lower Edges of Vehicle License Plate
