eSSL UHF1-Tag4 UHF Windshield Tag – UHF RFID Credential for Long Range Access

Rs. 50.00

~~Rs. 60.00~~ Rs. 50.00

Sale Sold out

UHF1-Tag4 – Ultra High Frequency Tag

The UHF1-Tag4 is a high-performance Ultra High Frequency (UHF) RFID tag designed for long-range identification and tracking applications. Featuring the reliable Alien H3 chip, the tag offers excellent read sensitivity, high security, and a service life of up to 10 years. Its adhesive design allows easy installation on vehicle windshields, making it ideal for parking management, vehicle access control, toll collection, and asset tracking applications.

Key Features

Operates on the global UHF frequency band of 860MHz – 960MHz
Long reading distance of up to 10 meters
High-performance Alien H3 RFID chip
Passive operation without battery
Data retention period up to 10 years
High reading speed and chip sensitivity
Supports repeated reading and writing operations
Anti-tear design for enhanced security
Adhesive backing for easy installation

Product Advantages

High security and reliable performance
Long service life and stable operation
Excellent long-range identification capability
Suitable for harsh operating environments
Ideal for vehicle and parking management systems
Flexible memory structure for various applications

Technical Specifications

Specification	Details
Model	UHF1-Tag4
Tag Type	Ultra High Frequency RFID Tag
Working Frequency	860MHz – 960MHz
Reading Distance	Up to 10 meters (Depending on reader and environment)
Protocol Standard	ISO/IEC 18000-6C, EPC Global Class 1 Gen 2
Chip	Alien H3
Working Mode	Passive (No Battery Required)
EPC Memory	96 Bits
UID/TID Memory	64 Bits
User Memory	512 Bits
Kill Password	32 Bits
Access Password	32 Bits
Erase Endurance	100,000 Times
Data Storage Period	10 Years
Working Temperature	0°C to 60°C
Storage Humidity	20% – 60% RH
Electrostatic Immunity	2KV (HBM)
Curvature	> 60mm
Dimensions	96.5 × 23.2 mm ±0.5 mm
Installation	Adhesive Mounting on Vehicle Windshield
