ZKTeco MA300 Outdoor Fingerprint & RFID Access Control Terminal

Rs. 10,856.00

~~Rs. 13,028.00~~ Rs. 10,856.00

Sale Sold out

ZKTeco MA300 Outdoor Fingerprint & RFID Access Control Terminal

The ZKTeco MA300 is a rugged outdoor fingerprint and RFID access control terminal designed for reliable and secure door management in harsh environments. Featuring a durable zinc alloy metallic casing and an IP65-rated waterproof and dustproof design, the MA300 delivers outstanding performance for both indoor and outdoor installations.

Powered by the advanced ZKFinger V10.0 algorithm, the MA300 provides fast and accurate fingerprint recognition while supporting RFID card authentication. With TCP/IP, RS485, and Wiegand communication interfaces, the terminal can operate as a standalone device or integrate seamlessly with third-party access control systems. Its vandal-resistant construction and comprehensive access control functions make it ideal for offices, factories, warehouses, residential buildings, and industrial facilities.

Key Features

Rugged zinc alloy metallic casing for enhanced durability.
IP65-rated waterproof and dustproof construction.
Supports fingerprint and RFID card authentication.
Advanced ZKFinger V10.0 algorithm for fast recognition.
Stores up to 1,500 fingerprint templates.
Supports up to 10,000 RFID cards.
100,000 transaction records capacity.
TCP/IP and RS485 communication.
Wiegand input and output for third-party integration.
Supports electric lock, door sensor, exit button, alarm, and doorbell.
Anti-passback function for enhanced security.
Vandal-proof design suitable for outdoor installations.
Can operate in standalone mode or with access control panels.
Compatible with ZKBio CVSecurity software.

Technical Specifications

Specification	Details
Model	ZKTeco MA300
Device Type	Outdoor Fingerprint & RFID Access Control Terminal
Fingerprint Capacity	1,500 Templates
Card Capacity	10,000 Cards
Transaction Capacity	100,000 Records
Fingerprint Algorithm	ZKFinger V10.0
Sensor Type	ZK Optical Sensor
Card Type	125kHz ID Card (Optional IC Card and HID Card)
Communication	TCP/IP, RS485, Wiegand Input & Output
Access Control Interface	Electric Lock, Door Sensor, Exit Button, Alarm
Output Interface	Lock Relay, Doorbell
Standard Functions	Time Zone, Group, Anti-Passback, User Privilege Management
Optional Functions	Mifare Card, HID Card, External USB Keypad
Supported Software	ZKBio CVSecurity
Protection Rating	IP65
Power Supply	DC 12V, 3A
Operating Temperature	-10°C to 55°C
Operating Humidity	10% to 90% RH
Dimensions	73 × 148 × 34.5 mm
Installation Type	Wall Mounted
