ZKTeco Mars-S1000 Swing Barrier Turnstile
ZKTeco Mars-S1000 Swing Barrier Turnstile
Couldn't load pickup availability
Product Details
Mars-S1000 Series – Swing Barrier Turnstile
The ZKTeco Mars-S1000 Series is a premium swing barrier turnstile designed to deliver an enhanced user experience, high safety, reliable operation, and integration-friendly access control. Combining an elegant design with robust construction, the Mars-S1000 Series is suitable for modern high-traffic pedestrian entrances.
The system uses a brushless motor drive unit and provides smooth swing barrier movement with low operating noise. With up to 12 infrared sensor pairs available as an option, the Mars-S1000 Series provides enhanced passage detection and anti-tailgating performance while maintaining a technical throughput of up to 30 people per minute.
Constructed from SUS304 stainless steel with optional SUS316 stainless steel construction, the Mars-S1000 Series offers excellent durability for demanding access control environments. Its 650 mm standard lane can also be expanded to up to 900 mm, providing flexibility for different installation requirements.
Key Features
Provides smooth and controlled pedestrian access with a modern design suitable for premium entrances and high-traffic environments.
Equipped with 8 pairs of infrared sensors as standard, with an option for up to 12 pairs to improve passage detection and anti-tailgating performance.
The brushless motor provides reliable and smooth swing barrier operation while supporting long-term performance.
With an MCBF of up to 5 million cycles, the Mars-S1000 Series is designed for demanding continuous-use access control applications.
Provides a technical throughput rate of up to 30 people per minute for efficient pedestrian movement.
Operates at a noise level below 60 dB, helping provide a comfortable environment in offices and other indoor facilities.
SUS304 stainless steel construction provides durability and a premium appearance, with SUS316 stainless steel available as an option.
The standard 650 mm lane can be configured up to 900 mm to accommodate different pedestrian access requirements.
Integrated LED indicators provide clear visual guidance and access status information to users.
Safety & Security Features
- 8 pairs of infrared sensors as standard
- Up to 12 pairs of infrared sensors available as an option
- Enhanced anti-tailgating performance
- Swing barrier access control
- LED status indicators
- Low-noise operation below 60 dB
- IP34 protection level
Design & Construction
- SUS304 stainless steel cabinet
- SUS304 stainless steel lid
- Acrylic barrier
- Tempered glass barrier available as an option
- SUS316 stainless steel cabinet available as an option
- Wooden case packaging
Applications
- Corporate Offices
- Commercial Buildings
- Premium Building Entrances
- Educational Institutions
- Factories and Industrial Facilities
- Government Buildings
- Financial Institutions
- Hotels and Hospitality Facilities
- Transportation Facilities
- Indoor and Sheltered Outdoor Locations
Specifications
| Parameter | Specification |
|---|---|
| Model Name | Mars-S1000 Series |
| Product Type | Swing Barrier Turnstile |
| Power Requirements | AC 100–120V / 200–240V, 50–60Hz |
| Working Power | 55W |
| Standby Power | 22W |
| Drive Unit | Brushless Motor |
| MCBF | 5 Million Cycles |
| Technical Throughput Rate | Up to 30 People per Minute |
| Barrier Movement | Swing |
| Noise Level | < 60 dB |
| Infrared Sensors | 8 Pairs Standard / Up to 12 Pairs Optional |
| LED Indicator | Supported |
| Working Temperature | -25°C to 65°C |
| Working Humidity | 20% – 95% RH, Non-condensing |
| Working Environment | Indoor / Outdoor if Sheltered |
| Lane Width | 650 mm Standard / Up to 900 mm Optional |
| Dimensions (L × W × H) | 1360 × 120 × 1020 mm (±5 mm) |
| Packed Dimensions (L × W × H) | 1510 × 365 × 1216 mm (2 Boxes) |
| Net Weight | 110 kg (±5 kg) |
| Gross Weight | 160 kg (±5 kg) |
| Cabinet Material | SUS304 Stainless Steel / SUS316 Stainless Steel Optional |
| Lid Material | SUS304 Stainless Steel |
| Barrier Material | Acrylic / Tempered Glass Optional |
| Packing Material | Wooden Case |
| Protection Level | IP34 |
Frequently Asked Questions
The Mars-S1000 Series is a swing barrier turnstile designed for secure, controlled, and efficient pedestrian access.
The standard configuration includes 8 pairs of infrared sensors. Up to 12 pairs can be configured as an option for enhanced passage detection and anti-tailgating performance.
The Mars-S1000 Series has a technical throughput rate of up to 30 people per minute, depending on the access control configuration and operating conditions.
The turnstile uses a brushless motor drive unit designed for smooth, reliable, and long-term operation.
The Mars-S1000 Series has a Mean Cycles Between Failure (MCBF) rating of up to 5 million cycles.
Yes. The standard lane width is 650 mm, with an optional configuration of up to 900 mm for wider pedestrian access requirements.
Yes. The turnstile can be installed outdoors when used in a sheltered environment. It has an IP34 protection level and supports a working temperature range of -25°C to 65°C.
The standard cabinet is made from SUS304 stainless steel. SUS316 stainless steel is available as an option, while the standard acrylic barrier can optionally be replaced with tempered glass.
