ZKTeco Saturn-S2200 Swing Barrier Turnstile
ZKTeco Saturn-S2200 Swing Barrier Turnstile
Regular price
Rs. 227,650.00
Regular price
Rs. 273,180.00
Sale price
Rs. 227,650.00
Quantity
Couldn't load pickup availability
Product Details
Saturn-S2200 Series Swing Barrier Turnstile
The ZKTeco Saturn-S2200 Series is an innovative swing barrier turnstile designed to provide a smooth, secure and efficient pedestrian passage experience. The series includes the Saturn-S2000 and Saturn-S2200 models and is suitable for modern access control environments.
The Saturn-S2200 Series features a durable SUS304 stainless steel chassis with an IP54 protection rating for resistance against water and dust. A built-in clutch enhances security, while multiple infrared sensors provide reliable anti-tailgating and anti-pinch protection.
The turnstile supports multiple authentication methods including RFID, fingerprint, QR code and facial authentication. It can also be integrated with ZKTeco C3 and InBio series controllers or compatible third-party access control controllers.
Key Features
- Innovative swing barrier turnstile design.
- Available in Saturn-S2200 models.
- SUS304 stainless steel chassis construction.
- IP54 water and dust protection.
- Built-in clutch for enhanced security.
- DC brushless motor for smooth and reliable operation.
- Average 1-second movement speed with adjustable opening and closing timing.
- 12 pairs of infrared sensors as standard.
- Up to 18 pairs of infrared sensors available as an option.
- Anti-tailgating protection.
- Anti-pinch safety protection.
- Automatic swing barrier opening during power failure.
- Fire alarm fail-state input support.
- Supports RFID, fingerprint, QR code and facial authentication.
- Compatible with C3, InBio and third-party controllers.
- Low-noise operation below 60dB.
- MCBF of up to 5 million cycles.
Product Advantages
- Durable stainless steel construction for demanding access control environments.
- IP54 protection makes the turnstile suitable for indoor and sheltered outdoor installations.
- Wide adjustable lane configuration supports different pedestrian access requirements.
- Supports authentication technologies from RFID to modern facial recognition.
- Multiple infrared sensors improve pedestrian safety and access security.
- Automatic emergency opening provides a clear evacuation route.
- Brushless DC motor provides smooth and quiet barrier movement.
- Compatible with existing ZKTeco access control infrastructure and third-party controllers.
- Suitable for standard pedestrian access as well as wider lanes for special applications.
Technical Specifications
| Specification | Details |
|---|---|
| Series | Saturn-S2200 Series |
| Models | Saturn-S2200 |
| Product Type | Swing Barrier Turnstile |
| Barrier Movement | Swing |
| Barrier Material | Light Gray Transparent Acrylic 305 × 555 × 10mm (Standard) Light Gray Transparent Acrylic 380 × 555 × 10mm (Optional) Stainless Steel required for 900–1200mm lane widths |
| Chassis Material | SUS304 Stainless Steel Chassis Body / Aluminum Alloy Gate Column |
| Chassis Colour | Gray (Standard) |
| Lid Material | Stainless Steel & Polycarbonate |
| Clutch | Equipped |
| Motor | DC Brushless Motor |
| Movement Speed | Average 1 Second per Movement |
| Lane Width | 600–900mm (Optional, Acrylic) Maximum 1200mm (Optional, Stainless Steel) |
| Wide Lane Application | Two-Wheeled Motorcycle Access |
| IR Sensors | 12 Pairs Standard / 18 Pairs Optional |
| Ingress Protection | IP54 (Water & Dust Proof) |
| Emergency Mode | Supported — Swing Barrier Opens Automatically |
| Flow Rate - Facial Authentication | 15 Passengers per Minute |
| Flow Rate - QR Code | 30 Passengers per Minute |
| Flow Rate - RFID | 35 Passengers per Minute |
| Security Features | Anti-Tailgating / Anti-Pinch / Clutch |
| Security Level | Medium |
| MCBF | 5 Million Cycles |
| MTTR | Less than 60 Minutes |
| Noise Level | Less than 60dB |
| Controller Compatibility | C3 Series / InBio Series / Third-Party Controller |
| Credential Options | RFID Reader: ProID Series / KR Series Fingerprint Reader: FR1200 / FR1500S |
| Authentication Methods | QR Code / RFID / Fingerprint / Facial Authentication |
| Motherboard Communication | Fire Alarm Port (Relay) / RS485 Port |
| Motherboard Function | System Configuration / Access Control |
| Fire Signal | Voltage-Free Contact Input |
| Supported Software | ZKBio CVSecurity |
| Dimension with Packing - Saturn-S2000 | 1580 × 340 × 1270mm (2 Pieces) |
| Dimension with Packing - Saturn-S2200 | 1580 × 340 × 1270mm |
| Packing Material | Wooden |
| Site Preparation | Flat & Level Finished Floor |
Authentication & Integration
- RFID Card Authentication
- Fingerprint Authentication
- QR Code Authentication
- Facial Authentication
- ProID Series RFID Readers
- KR Series RFID Readers
- FR1200 Fingerprint Reader
- FR1500S Fingerprint Reader
- ZKTeco C3 Series Controller Compatibility
- ZKTeco InBio Series Controller Compatibility
- Third-Party Controller Compatibility
Safety & Security Features
- 12 pairs of infrared sensors provide standard detection coverage.
- Up to 18 pairs of infrared sensors can be installed for enhanced protection.
- Anti-tailgating technology helps prevent unauthorized following entry.
- Anti-pinch protection helps protect pedestrians during barrier movement.
- Built-in clutch provides enhanced security.
- Voltage-free fire alarm input supports emergency integration.
- Swing barriers automatically open during power failure.
- Emergency opening provides a clear evacuation path.
Emergency Mode
- Automatic swing barrier opening during power failure.
- Fire alarm fail-state input supported.
- Voltage-free contact input for fire alarm integration.
- Provides unobstructed pedestrian evacuation during emergencies.
- Combines access control security with pedestrian safety.
Flow Rate
- Facial Authentication: Up to 15 passengers per minute.
- QR Code: Up to 30 passengers per minute.
- RFID: Up to 35 passengers per minute.
Applications
- Corporate Offices
- IT Parks and Business Parks
- Commercial Buildings
- Shopping Malls
- Factories and Industrial Facilities
- Educational Institutions
- Government Buildings
- Transportation Facilities
- Hotels and Hospitality Facilities
- Restricted Access Areas
- Wide-Lane Pedestrian Access
- Two-Wheeled Motorcycle Access
Why Choose Saturn-S2200?
- Premium SUS304 stainless steel construction.
- IP54 water and dust protection.
- 5 million MCBF for long-term operational reliability.
- DC brushless motor for smooth and quiet operation.
- Average 1-second barrier movement.
- Wide lane options from 600mm up to 1200mm.
- Supports RFID, fingerprint, QR code and facial authentication.
- Anti-tailgating and anti-pinch protection.
- Automatic emergency opening during power failure.
- Compatible with ZKTeco and third-party access controllers.
- Suitable for indoor and sheltered outdoor installations.
Ideal For
- Swing Barrier Turnstile
- Pedestrian Access Control Gate
- RFID Access Control Turnstile
- Face Recognition Turnstile
- Fingerprint Access Control Gate
- QR Code Access Gate
- Biometric Entrance Control
- High-Security Pedestrian Gate
- Wide Lane Access Control
- Commercial Entrance Security
- Industrial Access Management
Technical Specifications
