ZKTeco ZKX6550 X-Ray Baggage Scanner
ZKTeco ZKX6550 X-Ray Baggage Scanner
Couldn't load pickup availability
Product Details
ZKTeco ZKX6550 X-Ray Inspection System
The ZKTeco ZKX6550 is a professional X-ray inspection system designed to improve operators' ability to identify potential threats in briefcases, carry-on baggage and small cargo parcels. With a large 650 mm × 500 mm tunnel opening, the system provides an effective inspection solution for security checkpoints and high-traffic facilities.
The ZKX6550 uses a reliable dual-energy X-ray generator combined with advanced image processing algorithms to produce clear scanning images. This allows operators to visually identify suspicious or potentially dangerous items more quickly and accurately.
The system features an innovative biometric identification function for operators, helping improve system security and reducing the risk associated with forgotten passwords. Its ergonomic and modern design provides a practical inspection platform for professional security screening applications.
Key Features
- Dual-energy X-ray inspection technology.
- Large 650 mm × 500 mm inspection tunnel.
- Designed for briefcases, carry-on baggage and small cargo parcels.
- Advanced image algorithms provide clear scanning images.
- Innovative biometric identification function for operators.
- Helps improve operator authentication and system security.
- Steel penetration of up to 30 mm.
- Wire resolution of 36 AWG.
- Single-view inspection system.
- Maximum conveyor load of 120 kg with adequate load distribution.
- Conveyor speed of 0.20 m/sec.
- Supports ZKBio SIS software.
- RJ45 TCP/IP communication interface.
- Supports storage of up to 200,000 scanned images.
- Ergonomic and modern inspection system design.
- Cabinet X-ray radiation safety compliance.
Product Advantages
- Dual-energy imaging helps operators distinguish and identify potential threat items.
- Large tunnel dimensions accommodate a wide range of baggage and parcels.
- High steel penetration of up to 30 mm supports inspection of dense objects.
- Biometric operator identification improves system access security.
- Advanced image processing helps provide clear and detailed scanning images.
- Integrated ZKBio SIS software support enables professional inspection management.
- High-capacity image storage supports up to 200,000 scanned images.
- Modern ergonomic design helps operators perform security inspections efficiently.
Inspection & Imaging Technology
Dual-Energy X-Ray Generator
The ZKX6550 uses a dual-energy X-ray detector and generator system to provide detailed inspection images for identifying potential threat items.
High Steel Penetration
With a steel penetration capability of up to 30 mm, the system is designed to inspect dense baggage and cargo items effectively.
High Image Resolution
The system provides a wire resolution of 36 AWG and spatial resolution of 1.6 mm horizontal / 1.3 mm vertical for detailed image inspection.
Advanced Image Processing
Superior image algorithms help produce clear scanning images, allowing operators to visually examine baggage and identify suspicious objects.
Biometric Operator Identification
The integrated biometric identification function helps secure operator access and reduces the possibility of operators being unable to access the system because of forgotten passwords.
Safety & Security Features
- Dual-energy X-ray inspection technology.
- Biometric operator identification.
- Radiation leakage dosage below 0.5 μSv/h at 10 cm from the surface.
- Compliant with stated radiation safety standards for cabinet X-ray systems.
- Operator access security features.
- Single-view X-ray inspection.
Applications
- Airports and Transportation Facilities
- Government Buildings
- Corporate Offices
- Hotels and Hospitality Facilities
- Shopping Malls
- Stadiums and Sports Facilities
- Factories and Industrial Facilities
- Warehouses and Logistics Facilities
- Security Checkpoints
- Small Cargo Inspection
- Carry-on Baggage Inspection
- Briefcase and Parcel Inspection
General Specifications
| Parameter | Specification |
|---|---|
| Tunnel Dimensions (W × H) | 650 × 500 mm |
| Conveyor Speed | 0.20 m/sec |
| Conveyor Load | 120 kg, Adequate Distribution (Maximum Load) |
| Conveyor Height | 650 mm |
| Detector | Dual-Energy Detector |
| View | Single-View |
| Supported Software | ZKBio SIS |
| Communication Interface | RJ45 (TCP/IP) |
| Dimensions (L × W × H) | 2120 × 980 × 1381 mm |
| Console Dimensions (L × W × H) | 747 × 706 × 1279 mm |
| Package Dimensions (L × W × H) | 2395 × 1195 × 1680 mm |
| Console Package Dimensions (L × W × H) | 890 × 840 × 1502 mm |
| Gross Weight | 680 kg + 140 kg Console, With Package |
| Net Weight | 560 kg + 100 kg Console |
| Film Safety | ASA/ISO1600 |
| Certifications | CE-EMC, CE-MD, FCC sDOC, FDA |
X-Ray Generator & Image Performance
| Parameter | Specification |
|---|---|
| Anode Voltage | 140 kV |
| Tube Current | 0.5 mA |
| Wire Resolution | 36 AWG |
| Steel Penetration | 30 mm |
| Spatial Resolution | Horizontal Φ1.6 mm / Vertical Φ1.3 mm |
| Penetration Resolution | 32 AWG |
| Generator Cooling | Sealed Oil Bath with Forced Air |
| Beam Direction | Vertically Upward |
| X-Ray Converter Type | L-Shaped Detector Line |
Computer Specifications
| Parameter | Specification |
|---|---|
| Operating System | Windows 10 |
| RAM | 8 GB |
| Hard Drive | 128 GB SSD + 2 TB HDD |
| Maximum Storage | Up to 200,000 Scanned Images |
Operating Environment
| Parameter | Specification |
|---|---|
| System Power | 220 VAC ±10%, 50/60 Hz 110 VAC ±10%, 50/60 Hz |
| Power Consumption | < 300 W |
| Noise Level | < 58 dB(A) |
| Operating Temperature | -10°C to +45°C |
| Storage Temperature | -20°C to +60°C |
| Working Humidity | 5% – 95%, Non-condensing |
Health & Safety
Radiation Safety
The ZKX6550 has a stated radiation leakage dosage of < 0.5 μSv/h measured 10 cm from the surface. The system is stated to comply with radiation safety standards of < 5 μSv/h for cabinet X-ray systems.
Software & Connectivity
- ZKBio SIS supported.
- RJ45 Ethernet communication interface.
- TCP/IP communication.
- Image storage capacity of up to 200,000 scanned images.
- Integrated computer system for X-ray image inspection.
Why Choose ZKTeco ZKX6550?
- Large 650 × 500 mm inspection tunnel for baggage and parcel screening.
- Dual-energy X-ray technology for detailed inspection.
- Up to 30 mm steel penetration.
- Advanced image algorithms for clear scanning images.
- Biometric operator identification for enhanced system security.
- High-resolution imaging with 36 AWG wire resolution.
- Professional ZKBio SIS software support.
- Up to 200,000 scanned images can be stored.
- Suitable for transportation, commercial, industrial and institutional security applications.
Package Includes
- 1 × ZKTeco ZKX6550 X-Ray Inspection System
- 1 × Operator Console
- Integrated Computer System
- Supporting Installation Components
