ZKTeco FaceDepot-7BL with FP Face Recognition Terminal
ZKTeco FaceDepot-7BL with FP Face Recognition Terminal
Couldn't load pickup availability
Product Details
FaceDepot-7BL – Linux-Based Hybrid-Biometric Access Control Terminal
The FaceDepot-7BL is a Linux-based hybrid-biometric access control terminal featuring advanced visible light facial recognition. Designed for modern access control applications, the terminal combines facial recognition with optional fingerprint, card, and password authentication to provide flexible and secure user verification.
The terminal incorporates advanced anti-spoofing technology designed to protect against multiple presentation attack types, including laser, color and black-and-white photo attacks, video attacks, and 3D mask attacks. Its 7-inch touch screen and 2MP WDR low-light camera provide a user-friendly interface and reliable facial image capture.
Key Features
- Linux-based hybrid-biometric access control terminal.
- Visible light facial recognition technology.
- Advanced anti-spoofing algorithm.
- Protection against laser photo attacks.
- Protection against color and black-and-white photo attacks.
- Protection against video attacks.
- Protection against 3D mask attacks.
- Multiple verification methods including face, fingerprint, card, and password.
- 7-inch touch screen display.
- 2MP WDR low-light camera.
- Adjustable LED light brightness.
- Face capacity of up to 10,000 templates.
- Optional fingerprint capacity of up to 10,000 templates.
- Optional card capacity of up to 10,000 cards.
- Transaction capacity of up to 200,000 records.
Product Advantages
- Combines multiple biometric and credential verification methods in a single terminal.
- Visible light facial recognition provides convenient and touchless user authentication.
- Anti-spoofing technology helps improve protection against common facial presentation attacks.
- Large 7-inch touch screen provides a clear and intuitive user interface.
- High-capacity face recognition supports installations with large user populations.
- Optional fingerprint and card functions allow the terminal to be configured according to application requirements.
- Multiple communication interfaces provide flexible integration with access control systems.
- Supports third-party electric locks, door sensors, exit buttons, alarms, and auxiliary inputs.
Authentication Methods
- Visible Light Facial Recognition
- Fingerprint Authentication – Optional
- Card Authentication – Optional
- Password Authentication
Biometric & Anti-Spoofing Technology
The FaceDepot-7BL uses visible light facial recognition technology with a 2MP WDR low-light camera to provide convenient biometric authentication.
The terminal uses an anti-spoofing algorithm designed to defend against print attacks, including laser, color, and black-and-white photos, as well as video attacks and 3D mask attacks.
Users can be authenticated using face, fingerprint, card, or password verification, allowing the terminal to support different security requirements and user preferences.
Technical Specifications
| Specification | Details |
|---|---|
| Model | FaceDepot-7BL |
| Product Type | Linux-Based Hybrid-Biometric Access Control Terminal |
| Facial Recognition | Visible Light Facial Recognition |
| Biometric Algorithm | ZKFace V5.8 & ZKFinger V10.0 |
| Display | 7-Inch Touch Screen |
| Face Capacity | 10,000 |
| Fingerprint Capacity | 10,000, Optional |
| Card Capacity | 10,000, Optional |
| Transaction Capacity | 200,000 |
| CPU | 900 MHz Dual Core CPU |
| Memory | 512 MB RAM / 8 GB Flash |
| Camera | 2MP WDR Low-Light Camera |
| Light | Adjustable LED Light Brightness |
| Communication | TCP/IP, Wi-Fi Optional, Wiegand Input / Output, RS485 |
| Power Supply | 12V / 3A |
| Dimensions (W × H × D) | 91.93 × 202.93 × 21.5 mm |
| Operating System | Linux |
Card & Credential Options
- 125 kHz ID Card (EM) – Optional
- 13.56 MHz IC Card – Optional
- Fingerprint – Optional
- Password
- Face Recognition
Communication & Access Control Interfaces
- TCP/IP Communication
- Wi-Fi – Optional
- Wiegand Input
- Wiegand Output
- RS485
- Third-Party Electric Lock Interface
- Door Sensor Interface
- Exit Button Interface
- Alarm Output
- Auxiliary Input
Standard Functions
- ADMS
- T9 Input
- DST
- Camera
- 9-Digit User ID
- Access Levels
- Groups
- Holidays
- Anti-Passback
- Record Query
- Tamper Switch Alarm
- Multiple Verification Modes
Optional Functions
- 125 kHz ID Card (EM)
- 13.56 MHz IC Card
- Fingerprint Authentication
- Wi-Fi Connectivity
Applications
- Corporate Offices
- Commercial Buildings
- Factories and Industrial Facilities
- Educational Institutions
- Government Buildings
- Warehouses
- Hotels
- Residential Buildings
- High-Security Entrance Points
- Time Attendance Systems
- Access Control Systems
- Visitor and Identity Verification Systems
Why Choose FaceDepot-7BL?
- Advanced visible light facial recognition technology.
- Supports up to 10,000 face templates.
- Optional 10,000 fingerprint template capacity.
- Optional 10,000 card capacity.
- Supports face, fingerprint, card, and password verification.
- Advanced anti-spoofing against photo, video, and 3D mask attacks.
- 7-inch touch screen provides an easy-to-use interface.
- 2MP WDR low-light camera with adjustable LED brightness.
- Multiple communication and access control interfaces.
- Supports third-party electric locks and door accessories.
- Up to 200,000 transaction records.
Supported Software
The FaceDepot-7BL is supported by ZKBio Access IVS for access control management, user management, authentication configuration, and transaction monitoring.
Frequently Asked Questions
The FaceDepot-7BL supports up to 10,000 face templates.
Yes. Fingerprint authentication is available as an optional function, with a capacity of up to 10,000 fingerprint templates.
Yes. Card authentication is available as an optional function with a capacity of up to 10,000 cards. The terminal can support 125 kHz ID (EM) and 13.56 MHz IC cards through the appropriate optional configuration.
The FaceDepot-7BL supports face, fingerprint, card, and password verification, with fingerprint and card functionality available as optional configurations.
Yes. Its anti-spoofing algorithm is designed to protect against print attacks, including laser, color, and black-and-white photos, as well as video and 3D mask attacks.
The FaceDepot-7BL supports ZKBio Access IVS for access control management.
