ZKTeco FaceDepot-7CL(50000) Face Recognition Terminal
ZKTeco FaceDepot-7CL(50000) Face Recognition Terminal
Couldn't load pickup availability
Product Details
FaceDepot-7CL – Visible Light Facial Authentication Terminal
The FaceDepot-7CL is a Linux-based biometric access control terminal from the ZKTeco FaceDepot 7C Series, featuring advanced Visible Light Facial Authentication Technology. It is designed to provide fast, secure and convenient biometric authentication with support for facial recognition, RFID cards and password verification.
The terminal supports a large biometric capacity of up to 50,000 face templates and uses an advanced anti-spoofing algorithm designed to protect against various fake photo and video attacks. With an IP65 protection rating, the FaceDepot-7CL is dustproof and waterproof, making it suitable for demanding access control installations.
Key Features
- Visible Light Facial Authentication Technology.
- Up to 50,000 face templates with customized encryption chip.
- Multiple authentication methods: Face, RFID Card and Password.
- Advanced facial anti-spoofing technology against photo and video attacks.
- IP65-rated dustproof and waterproof design.
- 125 kHz ID Card and 13.56 MHz IC Card options.
- HD video door phone support through SIP Protocol Version 2.0.
- Wireless doorbell support as an optional function.
- Fast facial authentication with a recognition speed of less than 0.35 seconds.
- Touchless facial authentication distance of 30 cm to 200 cm.
Authentication Methods
Uses visible light facial recognition technology for fast and touchless biometric authentication with a recognition distance of 30 cm to 200 cm.
Supports 125 kHz ID cards as standard, with 13.56 MHz IC cards available as an optional function.
Users can authenticate through the integrated virtual keypad with support for passwords up to 8 digits.
Anti-Spoofing & Security
- Advanced facial anti-spoofing algorithm.
- Protection against fake facial photographs.
- Protection against video-based facial attacks.
- Visible Light Facial Authentication technology.
- FAR ≤ 0.01% for visible light facial authentication.
- FRR ≤ 0.02% for visible light facial authentication.
- Tamper switch alarm.
- Anti-passback support.
- Access levels, groups and holiday management.
Technical Specifications
| Specification | Details |
|---|---|
| Model | FaceDepot-7CL |
| Product Series | FaceDepot 7C Series |
| Display | 7" TFT Color Touch LED Screen, 600 × 1024 |
| Camera | WDR Binocular Camera, 1MP |
| Operating System | Linux |
| CPU | Dual Core @ 1GHz |
| RAM | 512MB |
| ROM | 8GB |
| Speaker | 8 ohm @ 1 W |
| Microphone | 1 microphone; Sensitivity: -32dB; Omni-directional; Signal-to-Noise Ratio: -32dB; Impedance: 2.2kΩ |
| Supplement Light | No |
| Authentication Method | Face / Card / Password (Virtual Keypad) |
| Face Template Capacity | 50,000 (1:N) |
| Card Capacity | 50,000 (1:N) Standard |
| User Capacity | 50,000 (1:N) Standard |
| Transaction Capacity | 300,000 |
| Password Capacity | 8 Digits |
| Biometric Authentication Speed | Less than 0.35 sec (Facial Authentication) |
| Touchless Facial Authentication Distance | 30 cm to 200 cm |
| False Acceptance Rate (FAR) | ≤ 0.01% (Visible Light Facial Authentication) |
| False Rejection Rate (FRR) | ≤ 0.02% (Visible Light Facial Authentication) |
| Card Type | ID Card @ 125 kHz (Standard) IC Card @ 13.56 MHz (Optional) |
| Communication | TCP/IP, Wi-Fi (Optional), Wiegand Input or Output, RS485, USB Type-A |
| Wi-Fi | IEEE 802.11b/g/n/ax @ 2.4 GHz (Optional) |
| USB | USB Type-A, USB Drive Only |
| RS485 | ZKTeco RS485 |
| Auxiliary Interfaces | Auxiliary Input, Electric Lock, Door Sensor, Exit Button, 12V Output |
| Access Control Interface | RS485 (RS485 Card Reader / Biometric Reader) |
| Standard Functions | ADMS, DST, Photo Capture, Event Photo Capture, Up to 14-digit User ID, Access Levels, Groups, Holidays, Anti-Passback, Record Query, Schedule Bell, Tamper Switch Alarm, Automatic Status Switch, Multiple Authentication Methods, SIP Client Version 2.0, ONVIF, AC Push and TA Push Protocol Switch, HTTPS / SSH Backend Access, T9 Keyboard Input |
| Optional Functions | IC Card, Wi-Fi, Wireless Doorbell |
| Video Intercom | ZKTeco Private Protocol via TCP/IP; Standard SIP Protocol. Supported indoor monitors include VT07-B01, VT07-B01-W, VT07-B22L and VT07-B26L-W. |
| Video Intercom Software | ZKBio CVSecurity |
| Mobile Applications | ZKBio Zlink, ZKBio Zexus |
| Power Supply | DC 12V 3A (Optional) |
| Dimensions | 214 × 115 × 22.3 mm (L × W × H) |
| Ingress Protection Rating | IP65 (Waterproof and Dustproof) |
| Operating Humidity | 10% to 90% RH (Non-condensing) |
| Supported Software | On-Premise: ZKBio CVSecurity (AC PUSH) & ZKBio Time (TA PUSH) Cloud-Based: ZKBio Zlink (Web Portal & Mobile App) |
| Certifications | ISO14001, ISO9001, CE, FCC, RoHS |
Communication & Connectivity
- TCP/IP communication.
- Optional 2.4 GHz Wi-Fi.
- Wiegand input or output.
- ZKTeco RS485 communication.
- USB Type-A interface for USB drive.
- Auxiliary input and 12V output.
- Electric lock connection.
- Door sensor connection.
- Exit button connection.
Video Intercom Features
The FaceDepot-7CL supports HD video door phone functionality through SIP Protocol Version 2.0 and can integrate with compatible indoor monitors and ZKTeco software platforms.
The terminal supports ONVIF compatibility with Profiles S, T, G, C, Q and A for supported video and intercom applications.
A wireless doorbell can be integrated as an optional function for supported installation requirements.
Applications
- Access Control Systems
- Time & Attendance
- Corporate Offices
- Commercial Buildings
- Secure Entry Points
- Video Door Phone Systems
- Biometric Authentication Systems
- Indoor and Outdoor Access Control Installations
Why Choose FaceDepot-7CL?
- Advanced Visible Light Facial Authentication technology.
- Large 50,000 face template capacity.
- 50,000 card and user capacity.
- Fast facial authentication in less than 0.35 seconds.
- 30 cm to 200 cm touchless facial authentication distance.
- IP65 waterproof and dustproof protection.
- Multiple authentication options including face, RFID card and password.
- Advanced anti-spoofing protection against facial photo and video attacks.
- Integrated access control interfaces and video intercom capabilities.
- Support for both on-premise and cloud-based software platforms.
