ZKTeco FaceDepot-7BL Face Recognition Terminal – 7-inch, 10,000 Faces, Access Control
ZKTeco FaceDepot-7BL Face Recognition Terminal – 7-inch, 10,000 Faces, Access Control
The ZKTeco FaceDepot-7BL is a 7-inch visible-light face recognition terminal for access control and time attendance, with a 2MP WDR low-light camera.
Key specifications
| Face capacity | 10,000 (1,00,000 optional) |
| Card capacity | 10,000 (optional) |
| Transaction capacity | 2,00,000 |
| Display | 7-inch touch screen |
| Camera | 2MP WDR low-light |
| Face speed | 1 s or less |
| Communication | TCP/IP, Wi-Fi (optional), Wiegand, RS485 |
| Power | 12V 3A |
| Dimensions | 91.93 × 202.93 × 21.5 mm |
| Operating temperature | 0 °C to 45 °C |
Who should purchase it?
Corporate lobbies, offices and campuses that want a large-screen touchless face terminal at the door.
How many users can it support?
Up to 10,000 faces (optional upgrade to 1,00,000), 10,000 cards (optional) and 2,00,000 transactions.
Which biometric methods does it support?
Face (1 second or less), card and password, with multiple verify modes. 125 kHz EM and 13.56 MHz IC cards are options, fingerprint is an option (offered on the store as the FaceDepot-7BL with FP), and palm is available as a customised build.
Does it support TCP/IP, USB, Wi-Fi or cloud connectivity?
TCP/IP, Wiegand input/output and RS485, with Wi-Fi as an option.
Does it support an attendance application?
ADMS push is standard, so the terminal connects to ADMS-compatible cloud attendance platforms.
Which software is compatible?
ZKBio CVAccess. For payroll and HRMS connectivity, see the integration section below.
Can it integrate with payroll and HRMS software?
Yes. AmpleTrails offers third-party software integration as an optional service at additional cost, quoted to your requirement. We connect attendance data from this device to the industry-leading payroll and HRMS platforms, including SAP SuccessFactors, Oracle HCM Cloud, Workday, ADP, UKG, Zoho People, Zoho Payroll, Darwinbox, Keka, greytHR, PeopleStrong, HROne, Ramco HCM, factoHR, sumHR, Spine HR, Paybooks, RazorpayX Payroll and TallyPrime, as well as custom ERP systems through API. See attendance API and HRMS integration.
Does it support access control?
Yes. It controls a third-party electric lock, door sensor, exit button, alarm output and auxiliary input, with access levels, groups, holidays and anti-passback.
What are the installation requirements?
Wall-mounted, powered by 12V 3A. Operating range 0 °C to 45 °C, 20% to 80% humidity. AmpleTrails installs and configures this device anywhere in India: mounting, network setup, software installation, employee enrolment and admin training. See installation services.
What is included in the box?
The box content list for this model is confirmed on your quotation – our team will share the current manufacturer details.
What is the warranty?
Supplied with the manufacturer warranty. The exact warranty term is stated on your invoice, and the AmpleTrails support team handles warranty claims for you.
What alternatives are available?
- ZKTeco FaceDepot-7BL with FP – same terminal with a fingerprint reader
- ZKTeco FaceDepot-7C (50000) – current 7-inch model with 50,000 capacity and IP65
- ZKTeco FaceDepot-7CL (50000) – 7-inch face and card terminal with IP65
- Browse all biometric attendance machines or the full ZKTeco attendance machines.
Buy with installation and support
AmpleTrails supplies, installs and supports ZKTeco FaceDepot-7BL across India. Call +91 90347 57673 or WhatsApp us for a quotation including installation.
