COSEC ACS2DCM Access Control System (2-Door MIFARE Kit)

The COSEC ACS2DCM is a compact, all-in-one 2-door access control solution designed for secure entry management without requiring a separate server. It combines controller hardware, software panel, and MIFARE card readers into a single integrated kit, making it ideal for small to medium enterprise deployments.

This system is built on Matrix’s COSEC platform with SSL encryption, ensuring secure communication between devices. It supports multiple access control rules and is suitable for organizations looking for a cost-effective yet powerful access management solution.

Key Features

Complete 2-Door Access Control Kit (Plug & Play Solution)
Includes COSEC PANEL200S Server Software
Includes COSEC ARC DC200S Controller
Includes 2 × COSEC READER CB MIFARE Card Readers
Supports up to 25,000 Users
Event Storage Capacity up to 500,000 Records
Standalone Operation – No External Server Required
Supports In/Out Mode or Two Independent Door Control
SSL Encrypted Communication for Secure Data Transfer
Supports 25+ Advanced Access Control Rules
Time-Zone Based Access Control
Anti-Passback Security Feature
2-Person Rule for High Security Areas
Guard Tour Monitoring Support
Real-Time Event Tracking and Time Stamping

System Advantages

Reduces infrastructure cost by eliminating dedicated server requirement
Easy installation with pre-integrated hardware and software
Centralized control of two doors from a single system
Highly scalable for future expansion
Secure and encrypted communication architecture
Suitable for both standalone and network-based deployment

Hardware Components

COSEC PANEL200S Management Server
COSEC ARC DC200S Two-Door Controller
2 × COSEC READER CB (BLE + RFID Readers)
CPM MIFARE Card Modules

Technical Highlights

Specification	Details
Door Control	2 Doors (Independent or In/Out Mode)
User Capacity	Up to 25,000 Users
Event Storage	Up to 500,000 Events
Authentication	MIFARE Card + Optional Mobile (via Reader CB)
Security	SSL Encrypted Communication
Access Rules	Time Zones, Anti-Passback, 2-Person Rule, Guard Tour
System Type	Standalone / Network Based Access Control

Applications

Corporate Offices
Small & Medium Enterprises
IT Parks
Warehouses
Educational Institutions
Industrial Sites
Restricted Entry Areas

Summary

COSEC ACS2DCM is a ready-to-deploy 2-door access control solution that combines hardware and software into a single kit. It provides strong security, advanced access rules, and easy deployment, making it ideal for organizations seeking a cost-effective and scalable access control system.
