Matrix Satatya MIDR20FL60CWS 2MP IR Dome Camera with 6mm Lens

Matrix Satatya MIDR20FL60CWS 2MP IR Dome Camera with 6mm Lens

The Matrix Satatya MIDR20FL60CWS 2MP IR Dome Camera is a compact surveillance solution designed for indoor environments demanding both discreet design and high-performance monitoring. With a 2MP SONY STARVIS CMOS sensor and advanced imaging technology, it delivers sharp, vibrant video even in low-light conditions. Its intelligent video analytics, cybersecurity compliance, and efficient bandwidth management make it an ideal choice for offices, retail stores, and public sector applications.

Features

2MP high-resolution video output (1920 x 1080 @30fps)

6mm fixed lens with a 54° horizontal field of view

SONY STARVIS CMOS sensor for low-light image clarity

True WDR (120dB) for balanced exposure in variable lighting

IR Range up to 30 meters for clear night surveillance

3D DNR for noise reduction and image clarity

Intelligent Video Analytics: Motion Detection, Tamper Detection, Tripwire, Intrusion

Quad Stream Support for flexible monitoring and recording

Region of Interest (ROI) for optimized streaming and storage

H.265, H.264, and MJPEG compression to minimize storage use

Up to 512GB SD card edge recording with NAS/SFTP support

Two-way audio (Premium variants) with noise filtering

STQC and ISO/IEC 27402 compliant for enhanced cybersecurity

Sleek, vandal-resistant dome design for indoor use

Technical Specifications

Image Sensor: 1/2.8" SONY CMOS (STARVIS Series)
Minimum Illumination: 0.01 Lux (Color) / 0 Lux (IR ON)
Lens: 6mm Fixed (HFOV: 54°, VFOV: 29.03°, DFOV: 62.96°)
Field of View: 54° Horizontal
Maximum Resolution: 1920 x 1080 @30fps
Video Compression: H.265, H.264, MJPEG
IR Range: Up to 30 meters
Audio (Premium Only): 1 Audio In / 1 Audio Out, Two-way Audio
SD Card Storage: Supports up to 512GB
Streaming Profiles: Quad Stream – multiple resolutions and frame rates
Bitrate: 128 kbps – 8 Mbps (CBR/VBR)
Shutter Speed: 1/15s to 1/100000s
WDR: True WDR (120dB)
SNR: > 70dB
Privacy Masks: Up to 3
Cybersecurity Compliance: ISO/IEC 27402, STQC ER
Protocols Supported: TCP/IP, HTTPS, RTSP, SNMP, SFTP, and more
Edge Recording: SD, NAS, SFTP support
Alerts: IP Conflict, Network Disconnect, Storage Full
Video Analytics: Motion, Tamper, Intrusion, Tripwire, Audio Exception (Premium)
Power Supply: PoE (IEEE 802.3af) / 12V DC
Camera Adjustment: Pan 0°–330°, Tilt 0°–75°, Rotate 0°–180°
Operating Temperature: Indoor Environment
Weight: Approx. 800g

Why Choose Matrix Satatya MIDR20FL60CWS 2MP IR Dome Camera?

Compact, intelligent, and secure the Matrix Satatya MIDR20FL60CWS Dome Camera is purpose-built for indoor surveillance. Its smart analytics, encrypted streaming, and efficient recording capabilities make it a top-tier choice for professionals seeking high-quality performance without compromising on design. Perfect for retail, offices, and public infrastructure where space and discretion matter.
