Matrix

SATATYA CIBR50VL12CWS Matrix Camera

Rs. 0.00

Sale Sold out

Matrix SATATYA CIBR50VL12CWS 5MP IR Bullet Varifocal IP Camera

The Matrix SATATYA CIBR50VL12CWS is a high-performance 5MP Bullet IP Camera designed for professional outdoor surveillance applications. Equipped with a SONY STARVIS sensor and a manual varifocal lens (2.7mm-13.5mm), the camera delivers superior image quality in low-light environments. Featuring H.265 compression, True WDR, smart streaming, advanced video analytics, and support for up to 512GB onboard storage, this camera is ideal for commercial and enterprise security deployments.

⬇ Download Datasheet PDF

Key Features

5MP Resolution (2592 × 1944)
SONY STARVIS Back-Illuminated Sensor
Manual Varifocal Lens (2.7mm-13.5mm)
P-Iris Control
50m IR Night Vision
H.265 Video Compression
True WDR (120dB)
High Signal-to-Noise Ratio (73dB)
Smart Streaming and Adaptive Streaming
Edge Recording Support
On-board Storage up to 512GB
Advanced Video Analytics
PoE (IEEE 802.3af) Support
IP66 Weatherproof Protection
IK10 Vandal Resistance

Why Choose Matrix SATATYA CIBR50VL12CWS?

Excellent low-light performance with SONY STARVIS technology.
Flexible field of view adjustment with manual varifocal lens.
True WDR technology ensures clear images in challenging lighting conditions.
Reduced bandwidth and storage requirements with H.265 compression.
Reliable outdoor performance with IP66-rated enclosure.
Advanced video analytics for intelligent surveillance.
Supports edge recording up to 512GB.

Applications

Office Buildings
Retail Stores
Warehouses
Factories
Banks and Financial Institutions
Educational Institutions
Hospitals
Hotels
Parking Areas
Commercial Complexes

Technical Specifications

Specification	Details
Resolution	5MP (2592 × 1944)
Image Sensor	1/2.8" SONY STARVIS CMOS Progressive Scan Sensor
Lens Type	Manual Varifocal
Focal Length	2.7mm - 13.5mm
Focus	Manual Focus
Aperture	F1.4 - F3.2
Field of View	HFOV: 101°-30°, VFOV: 72°-23°, DFOV: 137°-38°
Minimum Illumination	0.01 Lux (Color), 0 Lux (IR On)
IR Distance	50m
Video Compression	H.265, H.264, MJPEG
Frame Rate	1-30fps
Bitrate	128kbps - 16Mbps
Wide Dynamic Range	True WDR (120dB)
SNR	73dB
Noise Reduction	2D and 3D DNR
Storage	Micro SD Card up to 512GB, NAS
Video Analytics	Motion Detection, Tamper Detection, Trip Detection, Intrusion Detection, IP Conflict Detection, Network Disconnect, Storage Full, Time Triggered Events
Network Protocols	TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTCP, RTSP, PPPoE, SMTP, NTP, HTTPS, TLS/SSL, FTP, ICMP, IGMP v2/v3
ONVIF Profiles	S and G
Power Supply	12V DC / PoE (IEEE 802.3af)
Power Consumption	<8W
Operating Temperature	-20°C to 50°C
Humidity	Less than 90% RH (Non-condensing)
Dimensions	301.6 × 84 × 92.5 mm
Weight	840g
Storage Options	NAS, Micro SD Card
Protection	IP66 Weatherproof, IK10 Vandal Resistant
Certifications	CE, FCC, RoHS, BIS, IP66, IK10, UL
