SATATYA MIBR30FL28CWS – Professional Series Bullet IP Camera

SATATYA MIBR30FL28CWS is a 3MP Professional Series Bullet IP Camera designed for high-performance surveillance with advanced imaging, smart analytics, and efficient video compression. It is powered by Sony STARVIS technology and True WDR for reliable monitoring in challenging lighting environments.

Key Features of SATATYA MIBR30FL28CWS

SONY STARVIS 1/2.8" CMOS 3MP progressive scan sensor
H.265 compression for optimized bandwidth and storage usage
True WDR (120dB) for balanced image quality in all lighting conditions
Smart Streaming and Adaptive Streaming support
On-board storage support up to 512GB SD card
High Signal-to-Noise Ratio (>70dB) for clear video output
IR night vision support up to 30 meters
Built-in video analytics: Intrusion Detection, Trip Wire, Motion Detection
Edge recording with pre and post event support
Multiple stream profiles (up to 4 streams)
ROI, BLC, and advanced image enhancement features
ONVIF Profile S & G compatibility

Why Choose SATATYA MIBR30FL28CWS?

High-quality 3MP imaging for detailed surveillance coverage
Excellent low-light performance with STARVIS sensor technology
Efficient storage management with H.265 compression
Stable video output using True WDR (120dB)
Smart analytics for proactive security alerts
Flexible installation with PoE support
Suitable for indoor and outdoor security applications
Scalable solution for enterprise-level surveillance systems

System Requirements

Hardware Requirements

SATATYA MIBR30FL28CWS IP Camera unit
PoE switch (IEEE 802.3af) or 12V DC power supply
NVR or VMS recording system
Ethernet network (10/100 Mbps)
Optional SD card storage up to 512GB

Software Requirements

Video Management Software (VMS) or compatible NVR system
ONVIF-compatible surveillance platform
Web browser (Chrome / IE / Firefox legacy support)
Vendor configuration and monitoring tools

Network Requirements

Stable LAN/WAN connectivity
TCP/IP protocol support enabled
RTSP / HTTP / HTTPS streaming configuration
Sufficient bandwidth for 3MP video streaming

Technical Specifications

Parameter	Specification
Resolution	3MP (2048 × 1536)
Sensor	1/2.8" SONY STARVIS CMOS
Lens	2.8mm Fixed Lens
IR Range	Up to 30 meters
Video Compression	H.265 / H.264 / MJPEG
WDR	True WDR (120dB)
Storage	Up to 512GB SD Card
Streaming	Up to 4 Streams
Audio	Not specified / Model dependent
Network	TCP/IP, HTTP, RTSP, DHCP, DNS
Power	12V DC / PoE IEEE 802.3af
Operating Temperature	0°C to 50°C
Certification	BIS, CE, FCC, ONVIF S & G

Applications

Corporate Office Surveillance
Industrial Security Monitoring
Warehouse & Logistics Tracking
Retail Store Surveillance
Outdoor Perimeter Security
Public Area Monitoring

Product Overview

SATATYA MIBR30FL28CWS delivers reliable 3MP surveillance performance with advanced imaging technology, smart analytics, and efficient storage optimization. It is designed for modern security systems requiring accuracy, scalability
