MATRIX SATATYA NVR25608XCTS

Matrix SATATYA NVR25608XCTS (256 Channel 4K Network Video Recorder with 8 HDD Slots)

The Matrix SATATYA NVR25608XCTS is a high-performance 256-channel enterprise-grade Network Video Recorder designed for large-scale IP surveillance deployments. It supports 4K resolution recording, advanced decoding capabilities, and redundant power architecture for mission-critical security applications.

Engineered for high-density surveillance environments, this NVR delivers powerful video processing, scalable storage, and centralized management, making it ideal for smart cities, industrial complexes, transportation hubs, and large enterprise security systems.

Key Features

• Supports up to 256 IP camera inputs
• 4K Ultra HD recording and playback support
• Display outputs: 1 × VGA and 2 × DisplayPort
• Dual hot-swappable redundant power supply (1+1 configuration)
• 8 hot-swap SATA bays (3.5” / 2.5” HDD/SSD supported)
• Supports up to 10TB per HDD (storage drive not included)
• 4 × 1GbE network ports for recording and streaming
• Supports ONVIF and major IP camera brands
• Supports up to 12MP camera resolution input
• H.265 / H.264 / MJPEG compression formats

Technical Highlights

• IP Channels: 256
• Camera Resolution Support: 12MP / 8MP / 5MP / 3MP / 2MP / 1080P / D1 / CIF
• Local Decoding Capability: 1 × 4K / 4 × 3MP / 9 × 1080P / 12 × 720P / 16 × D1
• Video Compression: H.265, H.264, MJPEG
• Network Interface: 4 × 1GbE Ethernet ports
• Storage: 8 × Hot-swap SATA HDD/SSD bays
• Power Supply: Dual redundant hot-swap PSU (1+1)
• Display Outputs: 1 × VGA + 2 × DisplayPort

Advanced Storage & Performance Features

• High-capacity scalable storage architecture
• Hot-swappable HDD/SSD support for continuous operation
• Adaptive recording for optimized storage usage
• Multi-stream recording for bandwidth efficiency
• High-performance decoding for multi-screen monitoring

Remote Management & Monitoring

• Centralized monitoring and control system
• Remote live view and playback support
• Mobile client access for on-the-go monitoring
• Real-time alerts via SMS and Email
• Multi-user access and permission management

Why Choose Matrix SATATYA NVR25608XCTS?

• Designed for ultra-large 256-channel surveillance systems
• Redundant power supply ensures uninterrupted operation
• High scalability with 8 HDD/SSD hot-swap bays
• Supports multiple camera resolutions up to 4K and 12MP
• Efficient compression reduces storage and bandwidth usage
• Ideal for critical infrastructure security environments

Applications

• Smart city surveillance systems
• Airports, railway stations, and metro networks
• Large industrial plants and manufacturing units
• Government and defense installations
• Stadiums, malls, and public infrastructure projects
• Corporate campuses and IT parks

System Benefits

• Centralized monitoring of large-scale camera networks
• High reliability with redundant power architecture
• Flexible storage expansion with hot-swappable drives
• Improved performance with multi-network interface design
• Efficient bandwidth and storage optimization

Important Notes

• Hard disks/SSDs are not included with the system
• Actual storage capacity depends on HDD configuration
• Performance depends on camera bitrate and resolution
• Professional installation recommended for enterprise deployment

The Matrix SATATYA NVR25608XCTS is a powerful enterprise-grade 256-channel 4K NVR designed for large-scale surveillance applications. With redundant power, hot-swappable storage, and advanced decoding capabilities, it delivers unmatched reliability and performance for critical security infrastructures.
