Features of ANANT AUP USER100
Annual Upgradation Package (AUP) for ANANT UCS [su_table]
| Software Upgradation License for 12 Months |
| Get New Features, Software Upgrades and Firmwares before the License Validity |
| New AUP Validity Date will be 12 Months from the Current License Validity Date |
| No. of Users: 100 |
| Note: 1st year AUP license will come by default with the system, which will start from the day of installation |
[/su_table] [caption id="attachment_22513" align="aligncenter" width="972"]
Anant Server Based UC Platform ANANT AUP USER100
OPEN SERVER BASED PBX
ANANT UNIFIED COMMUNICATION SOFTWARE Traditional hardware-based PBXs are slowly getting replaced by open server-based telephony systems. This is largely because hardware-based PBXs create hardware dependency, require manual up-gradation and incur heavy wiring cost. Matrix has designed an enterprise-grade highly capable, durable, scalable, and efficient Unified Communication Software solution – ANANT UCS. The hardware-independent platform provides customers with a choice to select a reliable server as per their requirements. With a range of enterprise-grade calling features, it improves employees’ productivity and speeds up the decision-making process. ANANT UCS connects all the employees on a single platform. The employees can connect from anywhere at any time by installing Matrix VARTA on Laptops /Tablets /PCs /Smartphones devices of their choice. Our UC Server offers a range of enterprise-grade calling features that improve employees’ productivity and speeds up the decision making process. With an in-call redundant system, ANANT UCS boasts of providing the best customer engagement. By integrating ANANT with VoIP Gateways and IP Phones, customer requirements with multiple location communication set-up can be met.
PRODUCT HIGHLIGHTS
- 5000 IP Users
- 1024 Concurrent Calls
- 512 Three Party Conference
- 64 Simultaneous Call Recording
Key Features
- Hardware Independence
- Active-standby Redundancy
- RAID1 and RAID5 Support
- Mobility
- Auto Sign-in for Softphone
- LDAP Client Support
- Built-in Auto-attendant and Voicemail
- Auto Sync Configuration
- Scheduled Back-up
- Integration with VoIP Gateways
- Unified Messaging
- Room Monitor
- Least Cost Routing
- Hotline
TECHNICAL SPECIFICATIONS
[su_table]
| Parameter | Details |
| SIP Extensions | 5000 |
| SIP Trunks | 99 |
| Maximum Transcoding Audio Calls (a-Law/u-Law) | Based on Resources (Max. 1024) |
| Maximum Transcoding Audio Calls (G.729 | Based on Resources (Max. 1024) |
| Maximum DRTP/RTP Relay Audio Calls | 1024 |
| Maximum DRTP/RTP Relay Video Calls | 102 |
| Maximum Voicemail Channels | 64 |
| Maximum Conference Participants (System wide) | 1536 |
| Maximum 3-Party Conference | 512 |
| Maximum Participants in a Single Multi-Party or Dial-In Conference | 64 |
| Maximum Call Tapping or Recordings | 64 |
| Audio Codecs | G.729, G.711(A-law, μ-law), G.722, iLBC (30 ms, 20 ms) |
| Supported IETF RFCs | 3261, 3262, 3389, 3550, 3551, 3311, 3265, 4733, 2915, 2916, 2327, 2833, 2806, 768, 793, 1034 |
| Network Protocols | IPv6, IPv4, TCP, UDP, SNTP, ARP, ICMP, PPP, DNS, SMTP, STUN |
| VoIP Quality of Service | Support of Layer 2/3 CoS/QoS for SIP Support of Layer 3 QoS for RTP |
| Security | SRTP/TLS over SIP, MD5 Authentication for SIP, Password encrypted with AES128 algorithm |
| Configuration | Web-Based Intuitive GUI, Jeeves |
SERVER SPECIFICATIONS
| Parameter | Details |
| Server Model | Any |
| Processor Model | Intel Xeon E-2134 or above |
| CPU Speed | 3.5 GHz or above |
| CPU Core/Thread | 4/8 |
| Max Turbo Frequency | 4.5 GHz or above |
| Cache | 8 MB Smart Cache |
| RAM | 8 GB DDR4 ECC |
| Hard Disk | 1 TB (1 No.) - Without RAID Support 1 TB (2 Nos.) - With RAID1 Support 1 TB (3 Nos.) - With RAID5 Support |
| Form Factor | 1U (RACK) |
| Raid Controller (Optional) | H330 Raid Controller* |
TECHNICAL SPECIFICATIONS If you want to get more details please fill the form below. Our experts will contact you to give face attendance and various other solutions as per your requirements. Call us at 9315441078 or email us at info@ampletrails.com
