Matrix VISIONPRO308 Matrix EPABX for small business
Matrix VISIONPRO308 Matrix EPABX for small business
Regular price
Rs. 19,500.00
Regular price
Rs. 9,800.00
Sale price
Rs. 19,500.00
Unit price
/
per
Couldn't load pickup availability
The Matrix VISIONPRO308 is a compact and efficient Matrix EPABX designed for small businesses. With its advanced features, it simplifies communication and boosts productivity. Experience seamless connectivity and enhanced efficiency with the Matrix VISIONPRO308.
Matrix EPABX for small business
Specifications of Matrix VISIONPRO308
- Type of Switching: PCM/TDM, Digital Switching, 100% Non-blocking
- Processor: 16-bit DSP
- Signaling: Loop Start
- Dialing: DTMF and Pulse (10/20PPS)
- Off-Hook AC Impedance: 600/900/Complex
- Off-Hook Current: 39mA Max.
- Loop Limit: 1800Ω Max (Excluding Telephone)
- On-Hook Voltage (Tip/Ring): -48V nominal
- DTMF detection: ITU-T Q.24
- Return Loss: >18dB
- Longitudinal Balance: >50dB
- Transmission Level Adjust: Tx Gain: -12dB to +6dB, Rx Gain: -12dB to +6dB
- Ringing: Trapezoidal 50VRMS/25Hz and Sinusoidal 52VRMS/25Hz
- REN: 3
- CLI Presentation: DTMF, FSK ITU-T V.23 and FSK Bellcore 202
- Protection: Over Voltage Secondary Protection
- Physical Connector: 2.54mm Push Type connector
CO (Central Office)/Two-Wire Trunk (TWT)
- Signaling: Loop Start
- Loop Limit: 1200Ω
- Off-Hook AC Impedance: 600/900/Complex
- Pulse Dialing: 10/20 PPS
- DTMF Dialing and Reception: ITU-T Q.23 and Q.24
- Return Loss: >18dB
- Longitudinal Balance: >50dB
- Transmission Level Adjust: Tx Gain: -15dB to +10dB. Rx Gain: -15dB to + 10dB
- CLI Reception: DTMF, FSK ITU-T V.23 and FSK Bellcore 202
- Call Maturity Delay and Polarity Reversal:
- Protection: Over Voltage and Over Current Secondary Protection
- Physical Connector: 2.54mm Push Type connector
- Input: External Adapter 12V@2A for VISIONPRO 206, 308, 412
- Dimensions (W x H x D): 23.1 x 16.25 x 5.5 cm (10.5" x 11.2" x 3.1")
- Unit Weight: 0.65 kg (1.43lbs)
- Shipping Weight: 3.5 kg (7.7lbs)
- Installation: Wall Mount
- Operating Temperature: 0°C to 45 °C (+32°F to +122°F)
- Operating Humidity: 95% RH, Non-Condensing
Note: Specifications are subject to change without prior notice
